SHB-5W AC 85-265V to DC 12V 5W AC-DC Isolated Switching Power Supply Module Power Step Down Buck Regulator

Specifications: Model No. : SHB-5W Rated power: 5W V1 voltage: DC 5V+-2% current 100-700MA (main road) V2 voltage: DC 12V+-5% current 0-360MA (secondary) (Note: the sum of the main road power should not be greater than the rated power) Input voltage: AC 85V-264V Working efficiency: 75-82% Ripple voltage: AC2000V Isolation resistance: >200MR Voltage regulation rate 0.8% Load regulation rate 1% Opening time: 50MS Hold time: 20MS Transient response: 500US Temperature coefficient: 0.05%/C Working frequency: 50-150KHZ Working environment temperature -10/50 C V1--D is the main road 5V (V1 is +) V2--V3 is the secondary 12v (V2 is +) double group isolation Over temperature, overcurrent, short circuit protection Package Included: 1 x SHB-5W AC 85-265V to DC 12V 5W AC-DC Isolated Switching Power Supply Module
