SFU1204 600mm Ball Screw Anti Backlash Ballscrew with BK/BF10 Shaft Support CNC Parts

Description:SFU1204 600mm Ball Screw Anti Backlash Ballscrew with BK/BF10 Shaft Support CNC PartsSpecification:Model: SFU1204Material: Stainless steelNut diameter: 10mmLength ball screw: 600mmSize of coupler: 24*30mmDiameter of coupler hole: 6.35*8mmFeatures:High transmission efficiency, high positioning accuracy and repeatability of positioning accuracy, long life, high stiffness, drive transmission reversibility reversibility.Fused with shiny surface matching with high precision. More resistant to wear and tear, greatly extending the life cycle of the ball screw life increased several times.Installation method:1. The ball screw nut is inserted into the ball screw after the temporary locking. Position the nut in the middle of the ball screw shaft.2. The thrust ring and the fixed side of the BK12 support temporarily fixed in one side of the ball screw and tighten.3. BF12 support seat can be inserted into the another side of ball screw and the single row of bearings into the fixed.4. Finally, steeper Cooper inserted into ball screw and fixed in the outer side of the BF12 bearing.Package Included:1 x SFU1204-L600mm Ball Screw2 x BK/BF10 Support1 x 6.35x8mm Coupler1 x Locknuts1 x CirclipMore Details:
