SCOTT Speedster 20 Bike Medium - Green

The SCOTT Speedster is light, agile and cost efficient. The Speedster 20 features a Shimano groupset and Syncros components. You'll be upping your velocity in no time!
KEY FEATURES
Speedster Alloy Frame
Shimano Tiagra 20 Speed
Syncros Race 24 Rims
Schwalbe Lugano Tires
SPECIFICATIONS
FRAME
Speedster / 6061 D.Butted AlloyEndurance geometry / Integrated Headtube, int. cable routing
FORK
Speedster Carbon1 1/8"-1 1/4" Carbon steerer
REAR DERAILLEUR
Shimano Tiagra RD-4700-GS20 Speed
FRONT DERAILLEUR
Shimano Tiagra FD-4700
SHIFTERS
Shimano Tiagra ST-4700Dual control 20 Speed
CRANKSET
Shimano Tiagra FC-4700Hyperdrive 50x34 T
BB-SET
Shimano BB-RS500-PB
CHAIN
KMC X10
CASSETTE
Shimano CS-HG50010 Speed 11-32 T
BRAKES
Tektro BR-526Catridge Pads
HANDLEBAR
Syncros Creston 2.0 Compact31.8mm
H'STEM
JD ST123A Alloy1 1/8" / four Bolt 31.8mm
SEATPOST
Syncros RR2.5 27.2/350mm
SEAT
Syncros Tofino Regular 2.5
HEADSET
Integrated Steel Cup
HUB (FRONT)
Formula Team 24 H
HUB (REAR)
Formula Team 28 H
SPOKES
SHA-DAR Black 2mm
RIMS
Syncros Race 2424 Front / 28 Rear
FRONT TIRE
Schwalbe Lugano700x28C
REAR TIRE
Schwalbe Lugano700x28C
APPROX WEIGHTS IN KG
9.75
APPROX WEIGHTS IN LBS
21.50
MAX. SYSTEM WEIGHT
120 kgThe overall weight includes the bikethe riderthe equipmentand possible additional luggage.
GEOMETRY
MM
XXS/47
XS/49
S/52
M/54
L/56
XL/58
XXL/61
A
head tube angle
70.5 °
71.0 °
72.0 °
72.5 °
73.0 °
73.3 °
73.3 °
B
HEAD TUBE LENGTH
111.0 MM
121.0 MM
141.0 MM
161.0 MM
181.0 MM
201.0 MM
221.0 MM
C
TOP TUBE HORIZONTAL
505.0 MM
515.0 MM
530.0 MM
545.0 MM
560.0 MM
575.0 MM
590.0 MM
D
STANDOVER HEIGHT
725.3 MM
741.1 MM
767.5 MM
787.5 MM
807.5 MM
827.1 MM
851.4 MM
E
BB OFFSET
-67.0 MM
-67.0 MM
-67.0 MM
-67.0 MM
-67.0 MM
-67.0 MM
-67.0 MM
F
BB HEIGHT
282.0 MM
282.0 MM
282.0 MM
282.0 MM
282.0 MM
282.0 MM
282.0 MM
G
WHEEL BASE
973.1 MM
979.4 MM
981.2 MM
986.8 MM
991.6 MM
999.0 MM
1,012.7 MM
H
BB CENTER TO TOPTUBE CENTER
410.0 MM
430.0 MM
460.0 MM
480.0 MM
500.0 MM
520.0 MM
550.0 MM
I
BB CENTER TO TOP OF SEATTUBE
470.0 MM
490.0 MM
520.0 MM
540.0 MM
560.0 MM
580.0 MM
610.0 MM
J
SEAT ANGLE
75.0 °
75.0 °
74.5 °
74.0 °
73.5 °
73.1 °
73.0 °
K
CHAINSTAY
415.0 MM
415.0 MM
415.0 MM
415.0 MM
415.0 MM
415.0 MM
415.0 MM
L
REACH
366.6 MM
373.5 MM
377.3 MM
381.2 MM
384.6 MM
389.0 MM
397.0 MM
M
STACK
516.7 MM
527.9 MM
550.5 MM
571.3 MM
592.3 MM
612.5 MM
613.6 MM
N
STEM LENGTH
