SCOTT Small Sub Cross 50 Lady Bike - White

The SCOTT SUB Cross 50 emphasizes comfort and convenience for touring and transportation. The SUB Cross is set up perfectly for your excursions.
KEY FEATURES
Sub Cross Men/Lady Alloy Frame
Sub Cross Steel Rigid Fork
Shimano Tourney TX800 24 Speed
Tektro Hyd. Brakes
Kenda Booster
SPECIFICATIONS
FRAME
Sub Cross Alloy 6061 / Custom Butted tubing / Sub Cross Men/Lady Rigid geometry / SCOTT urban kit ready
FORK
Sub Cross Steel Rigid Fork
REAR DERAILLEUR
Shimano Tourney RD-TX800 / 24 Speed
FRONT DERAILLEUR
Shimano FD-TY710 / 34.9mm
SHIFTERS
Shimano SL-M315-8 / R-fire plus / w/gear indicator
CRANKSET
Shimano FC-TY301 / 48x38x28 / w/CG
BB-SET
Feimin FP-B908N / Cartridge Type
CHAIN
KMC Z-8.3
CASSETTE
Sunrace CSM55 8AV / 11-34T
BRAKES
Tektro HDM275 Hydr. Disc
ROTOR
Tektro / 6 bolts / F&R 160mm
HANDLEBAR
Men:JD-MTB11AFS / 660mm/9° bend / Lady:JD-HB-TR28AL / 660mm/15° bend
H'STEM
JD-ST161A / 7° / Black
SEATPOST
HL-SPC207 / 31.6mm / 350mm / Black
SEAT
Syncros UC3.0 / UC3.0W
HEADSET
Syncros OE Press Fit / 1 1/8"OD 50mm / ID 44mm
HUB (FRONT)
Formula DC-19 FQR Disc
HUB (REAR)
Formula DC-25 RQR Disc
SPOKES
14 G / stainless / black
RIMS
Syncros X-20 Disc / 32H / black
FRONT TIRE
Kenda Booster / 700x45C / 30 TPI
REAR TIRE
Kenda Booster / 700x45C / 30 TPI
PEDALS
Feimin FP-803
APPROX WEIGHTS IN KG
13
APPROX WEIGHTS IN LBS
28.66
MAX. SYSTEM WEIGHT
128 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
MMINCHES
S
M
L
XL
A
HEAD TUBE ANGLE
70.0 °
70.0 °
70.0 °
70.0 °
B
HEAD TUBE LENGTH
115.0 MM
130.0 MM
155.0 MM
180.0 MM
C
TOP TUBE HORIZONTAL
550.0 MM
565.0 MM
575.0 MM
590.0 MM
D
STANDOVER HEIGHT
679.5 MM
684.1 MM
695.8 MM
702.6 MM
E
BB OFFSET
56.0 MM
56.0 MM
56.0 MM
56.0 MM
F
BB HEIGHT
406.0 MM
406.0 MM
406.0 MM
406.0 MM
G
WHEEL BASE
1,067.0 MM
1,078.0 MM
1,083.0 MM
1,099.0 MM
H
BB CENTER TO TOPTUBE CENTER
I
BB CENTER TO TOP OF SEATTUBE
420.0 MM
460.0 MM
500.0 MM
540.0 MM
J
SEAT ANGLE
73.5 °
73.0 °
72.3 °
72.0 °
K
CHAINSTAY
456.0 MM
456.0 MM
456.0 MM
456.0 MM
L
REACH
374.0 MM
379.0 MM
375.9 MM
383.5 MM
M
STACK
N
STEM LENGTH
70.0 MM
80.0 MM
90.0 MM
100.0 MM
