SCOTT Roxter Jr 16" - Orange

The SCOTT Roxter 16 is our truly functional bike for smaller riders who like a race inspired style.
SPECIFICATIONS
FRAME
JR16 CoasterAlloy 6061 / Bended TTSemi int. HT / Rigid Fork
FORK
BMX Type / rigidHiTen / 16" / V-Brake Pivot
CRANKSET
One Piece Crank / 28T
BB-SET
Steel / loose ball bearings
CHAIN
KMC S1
CASSETTE
18T
BRAKE LEVERS
Kids Lever Alloy
BRAKES
F: V-Brake R: Coaster
HANDLEBAR
Junior mini Riser bar500mm
H'STEM
Ahead / Alloy / 30mm / 25.4mm clamp
SEATPOST
Alloy 26.8x200mm
SEAT
Syncros Roxter JR16
HEADSET
Semi integrated 1 1/8"
HUB (FRONT)
KT-183F / 20H / Nutted
HUB (REAR)
KT-305RB / 28H / Nuttedcoaster brake
SPOKES
15G UCP / black
RIMS
Alloy / black / 20H/28H / A/V
FRONT TIRE
Kenda K841 Contact / 16x2.25"
REAR TIRE
Kenda K841 Contact / 16x2.25"
PEDALS
MARWI SP-201 / 1/2" / w/Reflector
EXTRAS
Kickstand
ACCESSORIES
Syncros Stem Protector
APPROX WEIGHTS IN KG
8.20
APPROX WEIGHTS IN LBS
18.08
MAX. SYSTEM WEIGHT
50 kgThe overall weight includes the bikethe riderthe equipmentand possible additional luggage.
GEOMETRY
16''
A
HEAD TUBE ANGLE
70.0 °
B
HEAD TUBE LENGTH
3.5 IN
C
TOP TUBE HORIZONTAL
15.6 IN
D
STANDOVER HEIGHT
17.8 IN
E
BB OFFSET
F
BB HEIGHT
4.1 IN
G
WHEEL BASE
28.3 IN
H
BB CENTER TO TOPTUBE CENTER
6.1 IN
I
BB CENTER TO TOP OF SEATTUBE
8.3 IN
J
SEAT ANGLE
70.0 °
K
CHAINSTAY
11.4 IN
L
REACH
10.9 IN
M
STACK
12.8 IN
N
STEM LENGTH
0
TRAIL
