SCOTT Large Men's Sub Cross 40 Bike - Blue

The SCOTT SUB Cross 40 emphasizes comfort and convenience for touring and transportation. The SUB Cross is set up perfectly for your excursions.
KEY FEATURES
Sub Cross Men/Lady Alloy Frame
Zoom 187 D 63mm Fork
Shimano Altus M2000 27 Speed
Tektro Hyd. Brakes
Kenda Booster
SPECIFICATIONS
FRAME
Sub Cross Alloy 6061 / Custom Butted tubing / Sub Cross Men/Lady geometry / SCOTT urban kit ready
FORK
Zoom 187 D / 63mm travel
REAR DERAILLEUR
Shimano Altus RD-M2000 / 27 Speed
FRONT DERAILLEUR
Shimano FD-M370 / 34.9mm
SHIFTERS
Shimano SL-M2010-9 / R-fire plus / w/gear indicator
CRANKSET
Shimano FC-M371-L / 48x36x26 / w/CG
BB-SET
Feimin FP-B908N / Cartridge Type
CHAIN
KMC X9
CASSETTE
Shimano CS-HG200-911-32 T
BRAKES
Tektro HDM275 Hydr. Disc
ROTOR
Tektro / 6 bolts / F&R 160mm
HANDLEBAR
Syncros 3.0 / 31.8 / Men: Tbar/660mm/9° bend / Lady: 660mm/15° bend
H'STEM
Syncros 3.0 / 7° / Black
SEATPOST
Syncros 3.0 / 31.6mm / 350mm / Black
SEAT
Syncros UC3.0 / UC3.0W
HEADSET
Syncros OE Press Fit / 1 1/8"OD 50mm / ID 44mm
HUB (FRONT)
Formula DC-19 FQR Disc
HUB (REAR)
Formula DC-25 RQR Disc
SPOKES
14 G / stainless / black
RIMS
Syncros X-20 Disc / 32H / black
FRONT TIRE
Kenda Booster / 700x45C / 30 TPI
REAR TIRE
Kenda Booster / 700x45C / 30 TPI
PEDALS
Feimin FP-873-ZU
APPROX WEIGHTS IN KG
13.64
APPROX WEIGHTS IN LBS
30.07
MAX. SYSTEM WEIGHT
128 kgThe overall weight includes the bikethe riderthe equipmentand possible additional luggage.
GEOMETRY
MM
S
M
L
XL
XXL
A
HEAD TUBE ANGLE
70.0 °
70.0 °
70.0 °
70.0 °
70.0 °
B
HEAD TUBE LENGTH
105.0 MM
125.0 MM
145.0 MM
165.0 MM
185.0 MM
C
TOP TUBE HORIZONTAL
567.0 MM
577.0 MM
592.0 MM
608.0 MM
620.0 MM
D
STANDOVER HEIGHT
767.0 MM
793.0 MM
817.0 MM
847.0 MM
876.0 MM
E
BB OFFSET
56.0 MM
56.0 MM
56.0 MM
56.0 MM
56.0 MM
F
BB HEIGHT
406.0 MM
406.0 MM
406.0 MM
406.0 MM
406.0 MM
G
WHEEL BASE
1,078.0 MM
1,084.0 MM
1,097.0 MM
1,110.0 MM
1,123.0 MM
H
BB CENTER TO TOPTUBE CENTER
I
BB CENTER TO TOP OF SEATTUBE
450.0 MM
480.0 MM
510.0 MM
550.0 MM
590.0 MM
J
SEAT ANGLE
73.0 °
72.5 °
72.3 °
72.0 °
72.0 °
K
CHAINSTAY
456.0 MM
456.0 MM
456.0 MM
456.0 MM
456.0 MM
L
REACH
388.3 MM
386.8 MM
393.5 MM
399.8 MM
405.6 MM
M
STACK
N
STEM LENGTH
80.0 MM
90.0 MM
90.0 MM
100.0 MM
100.0 MM
