SCOTT Aspect 960 Extra Small - Florida Red

The SCOTT Aspect 960 is a hardtail mountain bike that is designed to be light, efficient and reasonably priced. Featuring disc brakes and Syncros components, this is the perfect bike for the novice or budget conscious mountain biker.Please note that bike specifications are subject to change without prior notice.
SPECIFICATIONS
FRAME
Aspect 900-700 series / Alloy 6061 Custom TubingBSA73 / Internal Cable Routing / replaceable hanger
FORK
Suntour XCE28100mm travel
REAR DERAILLEUR
Shimano Tourney RD-TX80016 Speed
FRONT DERAILLEUR
Shimano FD-M315-TS / 31.8mm
SHIFTERS
Shimano SL-M315R-fire plus / 2 way releasew/gear indicator
CRANKSET
Prowheel TM-CY0136X22 w/CG
BB-SET
Feimin FP.B908NBB73 / square taper
CHAIN
KMC Z-8.3
CASSETTE
Sunrace CSM55 8AV / 11-34T
BRAKES
Tektro HDM275 Hydr. Disc
ROTOR
Tektro / 6 bolt / F&R 160mm
HANDLEBAR
HL MTB-AL-312BT / 720mm / black / 12mm riseSncros Pro Grip
H'STEM
TDS-C301-8FOV / 10° / 31.8 / Black
SEATPOST
HL SP C20731.6mm / 350mm / Black
SEAT
Syncros 3.0
HEADSET
Syncros OE Press Fit / 1 1/8"OD 50mm / ID 44mm
HUB (FRONT)
Formula DC-19 FQR Disc
HUB (REAR)
Formula DC-25 8s RQR Disc
SPOKES
14 G / stainless / black
RIMS
Syncros X-20 Disc32H / black
FRONT TIRE
Kenda Booster2.4" / 30TPI
REAR TIRE
Kenda Booster2.4" / 30TPI
PEDALS
Feimin FP-873-ZU
APPROX WEIGHTS IN KG
14.60
APPROX WEIGHTS IN LBS
32.19
MAX. SYSTEM WEIGHT
128 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
INCHES
XS
S
M
L
XL
XXL
A
HEAD TUBE ANGLE
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
B
HEAD TUBE LENGTH
3.7 IN
3.9 IN
4.3 IN
4.7 IN
5.3 IN
5.9 IN
C
TOP TUBE HORIZONTAL
22.0 IN
23.0 IN
23.6 IN
24.2 IN
25.0 IN
25.8 IN
D
STANDOVER HEIGHT
29.3 IN
30.4 IN
30.8 IN
32.3 IN
33.7 IN
35.1 IN
E
BB OFFSET
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
F
BB HEIGHT
12.4 IN
12.4 IN
12.4 IN
12.4 IN
12.4 IN
12.4 IN
G
WHEEL BASE
43.4 IN
42.9 IN
43.4 IN
44.2 IN
45.0 IN
45.8 IN
H
BB CENTER TO TOPTUBE CENTER
12.2 IN
13.7 IN
15.5 IN
17.1 IN
19.1 IN
21.0 IN
I
BB CENTER TO TOP OF SEATTUBE
14.0 IN
15.6 IN
17.3 IN
18.9 IN
20.9 IN
22.8 IN
J
SEAT ANGLE
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
K
CHAINSTAY
17.7 IN
17.7 IN
17.7 IN
17.7 IN
17.7 IN
17.7 IN
L
REACH
15.3 IN
16.0 IN
16.5 IN
17.0 IN
17.6 IN
18.2 IN
M
STACK
22.8 IN
23.7 IN
24.1 IN
24.5 IN
25.0 IN
25.6 IN
N
STEM LENGTH
2.0 IN
2.4 IN
2.8 IN
3.1 IN
3.5 IN
3.9 IN
SIZE CHART
