SCOTT Aspect 950 - Slate/Grey

The SCOTT Aspect 950 is a hardtail mountain bike that is designed to be light, efficient and reasonably priced. Featuring disc brakes and Syncros components, this is the perfect bike for the novice or budget conscious mountain biker.Please note that bike specifications are subject to change without prior notice.
SPECIFICATIONS
FRAME
Aspect 900-700 series / Alloy 6061 Custom TubingBSA73 / Internal Cable Routing / replaceable hanger
FORK
Suntour XCT30-HLOHyd. Lockout / 100mm travel
REAR DERAILLEUR
Shimano Altus RD-M200018 Speed
FRONT DERAILLEUR
Shimano FD-M2020-TS / 31.8mm
SHIFTERS
Shimano SL-M2010R-fire plus / 2 way releasew/gear indicator
CRANKSET
Shimano FC-MT21022-piece Design / 36X22
BB-SET
Shimano BB-MT500Hollowtech II / threaded
CHAIN
KMC X9
CASSETTE
Shimano CS-HG200-9 / 11-36T
BRAKES
Tektro HDM275 Hydr. Disc
ROTOR
Tektro / 6 bolt / F&R 160mm
HANDLEBAR
Syncros 3.0 / 720mmblack / 31.8mm / 12mm rise / 9° BSSyncros Pro Grip
H'STEM
Syncros 3.0 / 7° / Black
SEATPOST
Syncros 3.031.6mm / 350mm / Black
SEAT
Syncros 3.0
HEADSET
Syncros OE Press Fit / 1 1/8"OD 50mm / ID 44mm
HUB (FRONT)
Formula DC-19 FQR Disc
HUB (REAR)
Formula DC-25 8s RQR Disc
SPOKES
14 G / stainless / black
RIMS
Syncros X-20 Disc32H / black
FRONT TIRE
Kenda Booster2.4" / 30TPI
REAR TIRE
Kenda Booster2.4" / 30TPI
PEDALS
Feimin FP-873-ZU
APPROX WEIGHTS IN KG
14.40
APPROX WEIGHTS IN LBS
31.75
MAX. SYSTEM WEIGHT
128 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
INCHES
XS
S
M
L
XL
XXL
A
HEAD TUBE ANGLE
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
B
HEAD TUBE LENGTH
3.7 IN
3.9 IN
4.3 IN
4.7 IN
5.3 IN
5.9 IN
C
TOP TUBE HORIZONTAL
22.0 IN
23.0 IN
23.6 IN
24.2 IN
25.0 IN
25.8 IN
D
STANDOVER HEIGHT
29.3 IN
30.4 IN
30.8 IN
32.3 IN
33.7 IN
35.1 IN
E
BB OFFSET
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
F
BB HEIGHT
12.4 IN
12.4 IN
12.4 IN
12.4 IN
12.4 IN
12.4 IN
G
WHEEL BASE
43.4 IN
42.9 IN
43.4 IN
44.2 IN
45.0 IN
45.8 IN
H
BB CENTER TO TOPTUBE CENTER
12.2 IN
13.7 IN
15.5 IN
17.1 IN
19.1 IN
21.0 IN
I
BB CENTER TO TOP OF SEATTUBE
14.0 IN
15.6 IN
17.3 IN
18.9 IN
20.9 IN
22.8 IN
J
SEAT ANGLE
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
K
CHAINSTAY
17.7 IN
17.7 IN
17.7 IN
17.7 IN
17.7 IN
17.7 IN
L
REACH
15.3 IN
16.0 IN
16.5 IN
17.0 IN
17.6 IN
18.2 IN
M
STACK
22.8 IN
23.7 IN
24.1 IN
24.5 IN
25.0 IN
25.6 IN
N
STEM LENGTH
2.0 IN
2.4 IN
2.8 IN
3.1 IN
3.5 IN
3.9 IN
SIZE CHART
