SCOTT Aspect 950 Large - Slate Grey

The SCOTT Aspect 950 is a hardtail mountain bike with no rear suspension, designed to be light, efficient and reasonably priced. The brakes are disc and Syncros components. It's the perfect model for beginners or budget-driven mountain bike users.
MAIN FEATURES
Aspect 700/900 alloy frame
Suntour XCT30-HLO 100mm
Shimano Altus, 18 speed
Tektro Hydraulic Hydraulic Disc Brakes
Kenda Booster
SPECIFICATIONS
FRAME - Aspect 900-700 Series / Custom 6061 BSA73 Alloy Tubing / Internal Wiring / Replaceable Hook
FORK - Suntour XCT30-HLO Hydraulic brakes / 100mm travel,
REAR DERAILLEUR - Shimano Altus RD-M2000 18 speed
FRONT DERAILLEUR - Shimano FD-M2020-TS / 31.8mm
SHIFTERS - Shimano SL-M2010 R-fire plus / Dual release with gear indicator
CRANKSET - Shimano FC-MT2102 2 Piece Design / 36X22
BB-SET - Shimano BB-MT500 Hollowtech II / threaded
CHAIN - KMC X9
CASSETTE - Shimano CS-HG200-9 / 11-36T
BRAKES - Tektro HDM275 hydr. Disc
ROTOR - Tektro / 6-bolt / 160mm front and rear
HANDLEBAR - Syncros 3.0 / 720mm black / 31.8mm / 12mm rise / 9 ° BS Syncros Pro grip
H'STEM - Syncros 3.0 / 7 ° / Black
SEATPOST - Syncros 3.0 31.6mm / 350mm / Black
SEAT - Syncros 3.0
HEADSET - Syncros OE Press Fit / 1 1/8 "OD 50mm / ID 44mm
HUB (FRONT) - Formula DC-19 FQR Disc
HUB (REAR) - Formula DC-25 8s RQR Disc
SPOKES - 14G / stainless / black
RIMS - Syncros X-20 Disc 32H / black
FRONT TIRE - Kenda Booster 2.4 "/ 30TPI
REAR TIRE - Kenda Booster 2.4 "/ 30TPI
PEDALS - Feimin FP-873-ZU
APPROX WEIGHTS IN KG - 14.40
APPROX WEIGHTS IN LBS - 31.75
MAX. SYSTEM WEIGHT - 128 kg The total weight includes the bicycle, the rider, the equipment and the additional luggage that is transported.
GEOMETRY
XS
S
M
L
XL
XXL
TO
HEAD TUBE ANGLE
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
B
HEAD TUBE LENGTH
95.0 MM
100.0 MM
110.0 MM
120.0 MM
135.0 MM
150.0 MM
C
HORIZONTAL TOP TUBE
560.0 MM
585.0 MM
600.0 MM
615.0 MM
635.0 MM
655.0 MM
D
STANDOVER HEIGHT
743.0 MM
771.0 MM
783.0 MM
821.0 MM
857.0 MM
891.0 MM
AND
BB OFFSET
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
F
BB HEIGHT
316.0 MM
316.0 MM
316.0 MM
316.0 MM
316.0 MM
316.0 MM
G
WHEEL BASE
1,102.0 MM
1,090.0 MM
1,102.0 MM
1,123.0 MM
1,144.0 MM
1,164.0 MM
H
BB CENTER TO TOPTUBE CENTER
309.0 MM
349.0 MM
394.0 MM
434.0 MM
484.0 MM
534.0 MM
I
BB CENTER TO TOP OF SEATTUBE
355.0 MM
395.0 MM
440.0 MM
480.0 MM
530.0 MM
580.0 MM
J
SEAT ANGLE
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
K
CHAINSTAY
450.0 MM
450.0 MM
450.0 MM
450.0 MM
450.0 MM
450.0 MM
L
REACH
388.0 MM
406.0 MM
419.0 MM
431.0 MM
447.0 MM
463.0 MM
M
STACK
580.0 MM
603.0 MM
612.0 MM
622.0 MM
636.0 MM
649.0 MM
N
STEM LENGTH
50.0 MM
60.0 MM
70.0 MM
80.0 MM
90.0 MM
100.0 MM
