SCOTT Aspect 940 Small - Granite

The SCOTT Aspect 940 is a hardtail mountain bike that is designed to be light, efficient and reasonably priced. Featuring a lockout mechanism for the fork, disc brakes and Syncros components, this is the perfect bike for the novice or budget conscious mountain biker.
KEY FEATURES
Aspect 700/900 Alloy Frame
Suntour XCR32-LO-R 100mm
Shimano Alivio 18 Speed
Shimano Brakes
Kenda Booster
SPECIFICATIONS
FRAME
Aspect 900-700 series / Alloy 6061 Custom Butted TubingBSA73 / Internal Cable Routing / replaceable hanger
FORK
Suntour XCR32/X1-RL-R / Hyd. Lockout / Reb. Adj.100mm travel
REAR DERAILLEUR
Shimano Alivio RD-M310018 Speed
FRONT DERAILLEUR
Shimano FD-M3120 Side Swing / 31.8mm
SHIFTERS
Shimano SL-M3100R-fire plus / 2 way releasew/gear indicator
CRANKSET
Shimano FC-MT21022-piece Design / 36X22
BB-SET
Shimano BB-MT500Hollowtech II / threaded
CHAIN
KMC X9
CASSETTE
Shimano CS-HG200-9 / 11-36T
BRAKES
Shimano MT200 / Hydr. Disc
ROTOR
Shimano SM-RT10 CL rotor / F&R 160mm
HANDLEBAR
Syncros 3.0 / 720mmblack / 31.8mm / 12mm rise / 9° BSSyncros Pro Grip
H'STEM
Syncros 3.0 / 7° / Black
SEATPOST
Syncros 3.031.6mm / 350mm / Black
SEAT
Syncros 3.0
HEADSET
Syncros OE Press Fit / 1 1/8"OD 50mm / ID 44mm
HUB (FRONT)
Shimano HB TX505
HUB (REAR)
Shimano FH-TX5058
SPOKES
14 G / stainless / black
RIMS
Syncros X-20 Disc32H / black
FRONT TIRE
Kenda Booster2.4" / 30TPI
REAR TIRE
Kenda Booster2.4" / 30TPI
PEDALS
VP VP-536
APPROX WEIGHTS IN KG
14.15
APPROX WEIGHTS IN LBS
31.20
MAX. SYSTEM WEIGHT
128 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
XS
S
M
L
XL
XXL
A
HEAD TUBE ANGLE
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
B
HEAD TUBE LENGTH
95.0 MM
100.0 MM
110.0 MM
120.0 MM
135.0 MM
150.0 MM
C
TOP TUBE HORIZONTAL
560.0 MM
585.0 MM
600.0 MM
615.0 MM
635.0 MM
655.0 MM
D
STANDOVER HEIGHT
743.0 MM
771.0 MM
783.0 MM
821.0 MM
857.0 MM
891.0 MM
E
BB OFFSET
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
F
BB HEIGHT
316.0 MM
316.0 MM
316.0 MM
316.0 MM
316.0 MM
316.0 MM
G
WHEEL BASE
1,102.0 MM
1,090.0 MM
1,102.0 MM
1,123.0 MM
1,144.0 MM
1,164.0 MM
H
BB CENTER TO TOPTUBE CENTER
309.0 MM
349.0 MM
394.0 MM
434.0 MM
484.0 MM
534.0 MM
I
BB CENTER TO TOP OF SEATTUBE
355.0 MM
395.0 MM
440.0 MM
480.0 MM
530.0 MM
580.0 MM
J
SEAT ANGLE
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
K
CHAINSTAY
450.0 MM
450.0 MM
450.0 MM
450.0 MM
450.0 MM
450.0 MM
L
REACH
388.0 MM
406.0 MM
419.0 MM
431.0 MM
447.0 MM
463.0 MM
M
STACK
580.0 MM
603.0 MM
612.0 MM
622.0 MM
636.0 MM
649.0 MM
N
STEM LENGTH
50.0 MM
60.0 MM
70.0 MM
80.0 MM
90.0 MM
100.0 MM
