SCOTT Aspect 940 Large - Granite

The SCOTT Aspect 940 is a hardtail mountain bike with no rear suspension, designed to be light, efficient and reasonably priced. The fork has a locking mechanism, the brakes are disc and Syncros components. It's the perfect model for beginners or budget-driven mountain bike users.
MAIN FEATURES
Aspect 700/900 alloy frame
Suntour XCR32-LO-R 100mm
Shimano Alivio, 18 speed
Shimano brakes
Kenda Booster
SPECIFICATIONS
FRAME
Aspect 900-700 Series / Tubes with 6061 BSA73 alloy reinforcements / Internal wiring / Replaceable hook
FORK
Suntour XCR32-LO-R / Hydraulic Lockout / Rebound Rebound Adjustment 100mm of travel
REAR DERAILLEUR
Shimano Alivio RD-M3100 18 speed
FRONT DERAILLEUR
Shimano FD-M3120 Side Swing / 31.8mm
SHIFTERS
Shimano SL-M3100 R-fire plus / Dual release with gear indicator
CRANKSET
Shimano FC-MT2102 2 Piece Design / 36X22
BB-SET
Shimano BB-MT500 Hollowtech II / threaded
CHAIN
KMC X9
CASSETTE
Shimano CS-HG200-9 / 11-36T
BRAKES
Shimano MT200 / Hidr. Disc
ROTOR
Shimano SM-RT10 CL / 160mm brake disc front and rear
HANDLEBAR
Syncros 3.0 / 720mm black / 31.8mm / 12mm rise / 9 ° BS Syncros Pro grip
H'STEM
Syncros 3.0 / 7 ° / Black
SEATPOST
Syncros 3.0 31.6mm / 350mm / Black
SEAT
Syncros 3.0
HEADSET
Syncros OE Press Fit / 1 1/8 "OD 50mm / ID 44mm
HUB (FRONT)
Shimano HB TX505
HUB (REAR)
Shimano FH-TX5058
SPOKES
14G / stainless / black
RIMS
Syncros X-20 Disc 32H / black
FRONT TIRE
Kenda Booster 2.4 "/ 30TPI
REAR TIRE
Kenda Booster 2.4 "/ 30TPI
PEDALS
VP VP-536
APPROX WEIGHTS IN KG
14.15
APPROX WEIGHTS IN LBS
31.20
MAX. SYSTEM WEIGHT
128 kg The total weight includes the bicycle, the rider, the equipment and the additional luggage that is transported.
GEOMETRY
XS
S
M
L
XL
XXL
A
HEAD TUBE ANGLE
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
B
HEAD TUBE LENGTH
95.0 MM
100.0 MM
110.0 MM
120.0 MM
135.0 MM
150.0 MM
C
TOP TUBE HORIZONTAL
560.0 MM
585.0 MM
600.0 MM
615.0 MM
635.0 MM
655.0 MM
D
STANDOVER HEIGHT
743.0 MM
771.0 MM
783.0 MM
821.0 MM
857.0 MM
891.0 MM
E
BB OFFSET
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
F
BB HEIGHT
316.0 MM
316.0 MM
316.0 MM
316.0 MM
316.0 MM
316.0 MM
G
WHEEL BASE
1,102.0 MM
1,090.0 MM
1,102.0 MM
1,123.0 MM
1,144.0 MM
1,164.0 MM
H
BB CENTER TO TOPTUBE CENTER
309.0 MM
349.0 MM
394.0 MM
434.0 MM
484.0 MM
534.0 MM
I
BB CENTER TO TOP OF SEATTUBE
355.0 MM
395.0 MM
440.0 MM
480.0 MM
530.0 MM
580.0 MM
J
SEAT ANGLE
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
K
CHAINSTAY
450.0 MM
450.0 MM
450.0 MM
450.0 MM
450.0 MM
450.0 MM
L
REACH
388.0 MM
406.0 MM
419.0 MM
431.0 MM
447.0 MM
463.0 MM
M
STACK
580.0 MM
603.0 MM
612.0 MM
622.0 MM
636.0 MM
649.0 MM
N
STEM LENGTH
50.0 MM
60.0 MM
70.0 MM
80.0 MM
90.0 MM
100.0 MM
