SCOTT Addict 40 Bike Medium - Prism Green

The ALL NEW SCOTT Addict 40 was designed from the ground up with those longer days in mind. With geometry that is less focused on racing and more on enduring, this bike is yearning to eat up some miles!
KEY FEATURES
Addict Disc HMF Carbon Frame
Addict HMF Fork
Shimano Tiagra Disc 20 Speed
Syncros Race 24 Disc Wheels
Schwalbe ONE Tires
Syncros Carbon/Alloy Parts
Please note that bike specifications are subject to change without prior notice
EVO-LAP TECHNOLOGY
With the proper selection of materials, eighty percent of the work to create a frame is done. But the remaining twenty percent requires most of our efforts. For this reason, our choice of the most advanced carbon fibers in the market is followed by intensive use of specific tools, like FEA (finite element analysis) software, to map out the carbon lay-up.
With FEA software, we can simulate different forces on a virtual model of the frame and adjust the frame construction accordingly. FEA software enables us to create complete virtual prototypes incorporating all the physical phenomena that exist in real-world environments.
With our Evo-Lap technology we model the frame to optimize the surface area, simulate tube structures with different ply orientations, observe the results of using different configurations, and test the stress distribution in different areas of the frame. Thanks to this extensive computer modeling, we’ve optimized the carbon layers in all the parts of our frame. When the parts were bonded together in the first prototypes, the result was a super light and compact frame without sacrificing the stiffness, comfort or impact resistance. The entire range benefitted from our Evo-Lap technology.
SPECIFICATIONS
FRAME
Addict Disc HMF CarbonEndurance geometry / Replaceable Derailleur HangerInternal cable routingSyncros fender kit ready
FORK
Addict HMF Disc1 1/4"-1 1/2" Eccentric Carbon steerer
REAR DERAILLEUR
Shimano Tiagra Black RD-4700-GS20 Speed
FRONT DERAILLEUR
Shimano 105 FD-R7000 Black
SHIFTERS
Shimano Tiagra ST-4720Dual Control 20 Speed
CRANKSET
Shimano Tiagra FC-4700 CompactHyperdrive 50x34 T
BB-SET
Shimano BB-RS500-PB
CHAIN
KMC X10
CASSETTE
Shimano CS-HG50010 Speed 11-32
BRAKES
Shimano BR-4770 Hyd.Disc
ROTOR
Shimano SM-RT64 CL rotor 160/F and 160/R
HANDLEBAR
Syncros Creston 2.0 CompactAlloy 31.8mm
H'STEM
Syncros RR2.01 1/4" / four Bolt 31.8mm
SEATPOST
Syncros RR1.227.2/350mm
SEAT
Syncros Tofino Regular 2.5 Channel
HEADSET
Acros AIF-1112
HUB (FRONT)
Formula Team II Disc 28 H
HUB (REAR)
Formula Team II Disc 28 H
SPOKES
14G Stainless Black 2mm
RIMS
Syncros Race 24 Disc28 Front / 28 Rear
FRONT TIRE
Schwalbe ONE Fold700x32C
REAR TIRE
Schwalbe ONE Fold700x32C
APPROX WEIGHTS IN KG
9.87
APPROX WEIGHTS IN LBS
21.76
MAX. SYSTEM WEIGHT
120 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
XXS/47
XS/49
S/52
M/54
L/56
XL/58
XXL/61
A
HEAD TUBE ANGLE
70.5 °
71.0 °
72.0 °
72.5 °
73.0 °
73.3 °
73.3 °
B
HEAD TUBE LENGTH
95.0 MM
105.0 MM
125.0 MM
145.0 MM
165.0 MM
185.0 MM
205.0 MM
C
TOP TUBE HORIZONTAL
515.0 MM
525.0 MM
540.0 MM
555.0 MM
570.0 MM
585.0 MM
600.0 MM
D
STANDOVER HEIGHT
732.0 MM
747.0 MM
775.0 MM
790.0 MM
812.0 MM
835.0 MM
848.0 MM
E
BB OFFSET
-70.0 MM
-70.0 MM
-70.0 MM
-70.0 MM
-70.0 MM
-70.0 MM
-70.0 MM
F
BB HEIGHT
275.3 MM
275.3 MM
275.3 MM
275.3 MM
275.3 MM
275.3 MM
275.3 MM
G
WHEEL BASE
996.7 MM
1,003.0 MM
1,005.0 MM
1,010.6 MM
1,015.4 MM
1,022.8 MM
1,036.5 MM
H
BB CENTER TO TOPTUBE CENTER
415.0 MM
435.0 MM
465.0 MM
485.0 MM
505.0 MM
525.0 MM
540.0 MM
I
BB CENTER TO TOP OF SEATTUBE
455.0 MM
475.0 MM
505.0 MM
525.0 MM
545.0 MM
565.0 MM
580.0 MM
J
SEAT ANGLE
75.0 °
75.0 °
74.5 °
74.0 °
73.5 °
73.1 °
73.0 °
K
CHAINSTAY
420.0 MM
420.0 MM
420.0 MM
420.0 MM
420.0 MM
420.0 MM
420.0 MM
L
REACH
376.3 MM
383.2 MM
387.0 MM
390.9 MM
394.3 MM
389.6 MM
406.6 MM
M
STACK
517.8 MM
529.1 MM
551.6 MM
572.4 MM
593.3 MM
613.6 MM
632.7 MM
N
STEM LENGTH
73.0 MM
83.0 MM
93.0 MM
103.0 MM
103.0 MM
113.0 MM
113.0 MM
