SCOTT 58 CM Speedster 50 Bike - Black/Blue

The SCOTT Speedster is light, agile and cost efficient. The Speedster 50 features a Shimano groupset and Syncros components. The best road bike by SCOTT you will be upping your velocity in no time!
KEY FEATURES
Speedster Alloy Frame
Shimano 14 Speed
Syncros Race 24 Rims
Schwalbe Lugano Tires
SPECIFICATIONS
FRAME
Speedster / D.Butted 6061 AlloyEndurance geometry / Integrated Headtube, int. cable routing
FORK
Speedster Alloy1 1/8" Alloy steerer
REAR DERAILLEUR
Shimano RD-A07014 Speed
FRONT DERAILLEUR
Shimano FD-A070
SHIFTERS
Shimano ST-A070Dual control 14 Speed
CRANKSET
Shimano FC-A07050x34T
BB-SET
Shimano BB-UN26
CHAIN
KMC Z-7
CASSETTE
Shimano CS-HG417 Speed 11-28 T
BRAKES
Tektro BR-315Catridge Pads 39-51mm
HANDLEBAR
Syncros Creston 2.0 Compact31.8mm
H'STEM
JD ST123A Alloy1 1/8" / four Bolt 31.8mm
SEATPOST
Syncros RR2.5 27.2/350mm
SEAT
Syncros Tofino Regular 2.5
HEADSET
Integrated Steel Cup
HUB (FRONT)
Formula Comp 24 H
HUB (REAR)
Formula Comp 28 H
SPOKES
SHA-DAR Black 2mm
RIMS
Syncros Race 2424 Front / 28 Rear
FRONT TIRE
Schwalbe Lugano700x28C
REAR TIRE
Schwalbe Lugano700x28C
APPROX WEIGHTS IN KG
10.50
APPROX WEIGHTS IN LBS
23.15
MAX. SYSTEM WEIGHT
120 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
MMINCHES
XXS/47
XS/49
S/52
M/54
L/56
XL/58
XXL/61
#REF!
#REF!
A
HEAD TUBE ANGLE
70.5 °
71.0 °
72.0 °
72.5 °
73.0 °
73.3 °
73.3 °
#REF!
B
HEAD TUBE LENGTH
93.0 MM
103.0 MM
123.0 MM
143.0 MM
163.0 MM
183.0 MM
203.0 MM
#REF!
#REF!
C
TOP TUBE HORIZONTAL
515.0 MM
525.0 MM
540.0 MM
554.0 MM
569.0 MM
583.0 MM
596.0 MM
#REF!
#REF!
D
STANDOVER HEIGHT
735.0 MM
754.0 MM
780.0 MM
800.0 MM
820.0 MM
840.0 MM
864.0 MM
#REF!
#REF!
E
BB OFFSET
-70.0 MM
-70.0 MM
-70.0 MM
-70.0 MM
-70.0 MM
-70.0 MM
-70.0 MM
#REF!
#REF!
F
BB HEIGHT
275.3 MM
275.3 MM
275.3 MM
275.3 MM
275.3 MM
275.3 MM
275.3 MM
#REF!
#REF!
G
WHEEL BASE
1,001.5 MM
1,007.9 MM
1,010.0 MM
1,015.8 MM
1,023.3 MM
1,030.3 MM
1,043.0 MM
#REF!
#REF!
H
BB CENTER TO TOPTUBE CENTER
430.0 MM
450.0 MM
480.0 MM
500.0 MM
520.0 MM
540.0 MM
570.0 MM
#REF!
#REF!
I
BB CENTER TO TOP OF SEATTUBE
470.0 MM
490.0 MM
520.0 MM
540.0 MM
560.0 MM
580.0 MM
610.0 MM
#REF!
#REF!
J
SEAT ANGLE
75.0 °
75.0 °
74.5 °
74.0 °
73.5 °
73.1 °
73.0 °
#REF!
K
CHAINSTAY
425.0 MM
425.0 MM
425.0 MM
425.0 MM
427.0 MM
427.0 MM
427.0 MM
#REF!
#REF!
L
REACH
376.0 MM
383.0 MM
387.0 MM
391.0 MM
385.0 MM
399.0 MM
406.0 MM
#REF!
#REF!
M
STACK
517.8 MM
529.1 MM
551.6 MM
572.4 MM
593.3 MM
613.6 MM
632.7 MM
#REF!
#REF!
N
STEM LENGTH
83.0 MM
83.0 MM
93.0 MM
103.0 MM
103.0 MM
113.0 MM
113.0 MM
#REF!
#REF!
