SCOTT 24" Contessa Junior Disc Bike - Matte Purple

The SCOTT Contessa 24 Disc has our classic trendy Contessa look, front suspension and disc brakes for improved stopping power.
KEY FEATURES
Scale 24 Disc Junior Alloy Frame
SR Suntour XCT-JR 24 Disc Fork
Shimano Tourney 8 Speed
Tektro Disc Brakes
Kenda Booster
SPECIFICATIONS
FRAME
Scale 24 Disc JuniorAlloy 6061 / Semi int. HTSCOTT dropout / IS
FORK
SR Suntour XCT-JR 24 Disc50mm travelSofter spring setup
REAR DERAILLEUR
Shimano RD-TX800 Tourney8 Speed
SHIFTERS
Shimano SL-RS45-8RRevo Shifter
CRANKSET
Prowheel / Alloy Crank 140mm32T / w/CG PVG double cover
BB-SET
Feimin / BB68 / cartridge / square taper
CHAIN
KMC Z8.3
CASSETTE
SunRace CSM558 Speed / 11-34T
BRAKE LEVERS
Tektro TS325A
BRAKES
Tektro SCM-02Mech. Disc Brake / 160mm rotor
HANDLEBAR
Junior Flat-Bar / Alloy560mm / Syncros Youth 100/80 Grip
H'STEM
LEADTEC LCS-713050mm / 25.4mm clamp
SEATPOST
Alloy / 26.8mm / 300mm
SEAT
Syncros Youth
HEADSET
Feimin FP-H807, 1 1/8" Semi Int.
HUB (FRONT)
Formula DC-19-F / QR
HUB (REAR)
Formula DC-25-7-R / QR
SPOKES
15g / UCP / black
RIMS
Alex C-1000 Disc
FRONT TIRE
Kenda K1227 Booster / 24x2.2" / 30TPI
REAR TIRE
Kenda K1227 Booster / 24x2.2" / 30TPI
PEDALS
MARWI SP-700 / w/Reflector
EXTRAS
Kickstand
ACCESSORIES
Syncros Stem Protector
APPROX WEIGHTS IN KG
12
APPROX WEIGHTS IN LBS
26.46
MAX. SYSTEM WEIGHT
50 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
24"
A
HEAD TUBE ANGLE
69.0 °
B
HEAD TUBE LENGTH
100.0 MM
C
TOP TUBE HORIZONTAL
500.0 MM
D
STANDOVER HEIGHT
584.8 MM
E
BB OFFSET
F
BB HEIGHT
G
WHEEL BASE
985.0 MM
H
BB CENTER TO TOPTUBE CENTER
I
BB CENTER TO TOP OF SEATTUBE
310.0 MM
J
SEAT ANGLE
68.0 °
K
CHAINSTAY
415.0 MM
L
REACH
M
STACK
N
STEM LENGTH
50.0 MM
0
TRAIL
SIZE GUIDE
