SCOTT 2021 Aspect 940 Bike Medium - Granite

The SCOTT Aspect 940 is a mountain hardtail that is designed to be light, efficient and reasonably priced. Featuring a lockout mechanism for the fork, disc brakes and Syncros components, this is the perfect bike for the novice or budget conscious mountain biker.
SPECIFICATIONS
FRAME
Aspect 900-700 series / Alloy 6061 Custom Butted TubingBSA73 / Internal Cable Routing / replaceable hanger
FORK
Suntour XCR32/X1-RL-R / Hyd. Lockout / Reb. Adj.100mm travel
REAR DERAILLEUR
Shimano Alivio RD-M310018 Speed
FRONT DERAILLEUR
Shimano FD-M3120 Side Swing / 31.8mm
SHIFTERS
Shimano SL-M3100R-fire plus / 2 way releasew/gear indicator
CRANKSET
Shimano FC-MT21022-piece Design / 36X22
BB-SET
Shimano BB-MT500Hollowtech II / threaded
CHAIN
KMC X9
CASSETTE
Shimano CS-HG200-9 / 11-36T
BRAKES
Shimano MT200 / Hydr. Disc
ROTOR
Shimano SM-RT10 CL rotor / F&R 160mm
HANDLEBAR
Syncros 3.0 / 720mmblack / 31.8mm / 12mm rise / 9° BSSyncros Pro Grip
H'STEM
Syncros 3.0 / 7° / Black
SEATPOST
Syncros 3.031.6mm / 350mm / Black
SEAT
Syncros 3.0
HEADSET
Syncros OE Press Fit / 1 1/8"OD 50mm / ID 44mm
HUB (FRONT)
Shimano HB TX505
HUB (REAR)
Shimano FH-TX5058
SPOKES
14 G / stainless / black
RIMS
Syncros X-20 Disc32H / black
FRONT TIRE
Kenda Booster2.4" / 30TPI
REAR TIRE
Kenda Booster2.4" / 30TPI
PEDALS
VP VP-536
APPROX WEIGHTS IN KG
14.15
MAX. SYSTEM WEIGHT
128 kgThe overall weight includes the bikethe riderthe equipmentand possible additional luggage.
GEOMETRY
XS
S
M
L
XL
XXL
A
HEAD TUBE ANGLE
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
B
HEAD TUBE LENGTH
95.0 MM
100.0 MM
110.0 MM
120.0 MM
135.0 MM
150.0 MM
C
TOP TUBE HORIZONTAL
560.0 MM
585.0 MM
600.0 MM
615.0 MM
635.0 MM
655.0 MM
D
STANDOVER HEIGHT
743.0 MM
771.0 MM
783.0 MM
821.0 MM
857.0 MM
891.0 MM
E
BB OFFSET
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
-60.0 MM
F
BB HEIGHT
316.0 MM
316.0 MM
316.0 MM
316.0 MM
316.0 MM
316.0 MM
G
WHEEL BASE
1,102.0 MM
1,090.0 MM
1,102.0 MM
1,123.0 MM
1,144.0 MM
1,164.0 MM
H
BB CENTER TO TOPTUBE CENTER
309.0 MM
349.0 MM
394.0 MM
434.0 MM
484.0 MM
534.0 MM
I
BB CENTER TO TOP OF SEATTUBE
355.0 MM
395.0 MM
440.0 MM
480.0 MM
530.0 MM
580.0 MM
J
SEAT ANGLE
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
K
CHAINSTAY
450.0 MM
450.0 MM
450.0 MM
450.0 MM
450.0 MM
450.0 MM
L
REACH
388.0 MM
406.0 MM
419.0 MM
431.0 MM
447.0 MM
463.0 MM
M
STACK
580.0 MM
603.0 MM
612.0 MM
622.0 MM
636.0 MM
649.0 MM
N
STEM LENGTH
50.0 MM
60.0 MM
70.0 MM
80.0 MM
90.0 MM
100.0 MM
