SCOTT 2021 Aspect 930 - Pearl White | Aluminium Alloy | Shimano FD-M4100

The SCOTT Aspect 930 is a mountain hardtail that is designed to be light, efficient and reasonably priced. Featuring a remote lockout mechanism for the fork, disc brakes and Syncros components, this is the perfect bike for the novice or budget conscious mountain biker.
SPECIFICATIONS
FRAME
Aspect 900 series / Alloy 6061 Custom Butted TubingBSA73 / Internal Cable Routing / replaceable hanger
FORK
Suntour XCR32/X1-RL-RRemote Lockout / Reb. Adj.100mm travel
REMOTE SYSTEM
Suntour Remote lockout
REAR DERAILLEUR
Shimano Deore RD-M412020 Speed
FRONT DERAILLEUR
Shimano FD-M4100 Side Swing / 31.8mm
SHIFTERS
Shimano SL-M4100R-fire plus / 2 way releasew/gear indicator
CRANKSET
Shimano FC-M4100-22-piece Design / 36X26
BB-SET
Shimano BB-SM-BB52Hollowtech II / threaded
CHAIN
KMC X10
CASSETTE
Shimano CS-M4100-10 / 11-42T
BRAKES
Shimano MT200 / Hydr. Disc
ROTOR
Shimano SM-RT10 CL / 180/F and 160/R
HANDLEBAR
Syncros 3.0 / 720mmblack / 31.8mm / 12mm rise / 9° BSSyncros Comfort Lock-on Grip
H'STEM
Syncros 3.0 / 7° / Black
SEATPOST
Syncros 3.031.6mm / 350mm / Black
SEAT
Syncros 3.0
HEADSET
Syncros OE Press Fit / 1 1/8"OD 50mm / ID 44mm
HUB (FRONT)
Formula CL51
HUB (REAR)
Shimano FH-TX5058
SPOKES
14 G / stainless / black
RIMS
Syncros X-20 Disc32H / black
FRONT TIRE
Kenda Booster2.4" / 30TPI
REAR TIRE
Kenda Booster2.4" / 30TPI
PEDALS
VP VP-536
APPROX WEIGHTS IN KG
13.95
MAX. SYSTEM WEIGHT
128 kgThe overall weight includes the bikethe riderthe equipmentand possible additional luggage.
GEOMETRY
XS
S
M
L
XL
XXL
A
HEAD TUBE ANGLE
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
68.5 °
B
HEAD TUBE LENGTH
3.7 IN
3.9 IN
4.3 IN
4.7 IN
5.3 IN
5.9 IN
C
TOP TUBE HORIZONTAL
22.0 IN
23.0 IN
23.6 IN
24.2 IN
25.0 IN
25.8 IN
D
STANDOVER HEIGHT
29.3 IN
30.4 IN
30.8 IN
32.3 IN
33.7 IN
35.1 IN
E
BB OFFSET
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
-2.4 IN
F
BB HEIGHT
12.4 IN
12.4 IN
12.4 IN
12.4 IN
12.4 IN
12.4 IN
G
WHEEL BASE
43.4 IN
42.9 IN
43.4 IN
44.2 IN
45.0 IN
45.8 IN
H
BB CENTER TO TOPTUBE CENTER
12.2 IN
13.7 IN
15.5 IN
17.1 IN
19.1 IN
21.0 IN
I
BB CENTER TO TOP OF SEATTUBE
14.0 IN
15.6 IN
17.3 IN
18.9 IN
20.9 IN
22.8 IN
J
SEAT ANGLE
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
73.5 °
K
CHAINSTAY
17.7 IN
17.7 IN
17.7 IN
17.7 IN
17.7 IN
17.7 IN
L
REACH
15.3 IN
16.0 IN
16.5 IN
17.0 IN
17.6 IN
18.2 IN
M
STACK
22.8 IN
23.7 IN
24.1 IN
24.5 IN
25.0 IN
25.6 IN
N
STEM LENGTH
2.0 IN
2.4 IN
2.8 IN
3.1 IN
3.5 IN
3.9 IN
