SCOTT 2021 Addict 10 Disc - Marine Blue | Carbon Frame | Shimano Ultegra FD-R8000

The SCOTT Addict 10 Disc was designed from the ground up with those longer days in mind. With geometry that is less focused on racing and more on enduring, a Shimano Ultegra drivetrain and disc brakes, the Addict 10 will be your go-to when you're looking to put the miles in.
SPECIFICATIONS
FRAME
Addict Disc HMF Carbon technologyEndurance geometry / Replaceable Derailleur Hanger
FORK
Addict Disc HMF1 1/8"-1 1/4" Carbon steererAlloy Dropout
REAR DERAILLEUR
Shimano Ultegra RD-R8000-GS22 Speed
FRONT DERAILLEUR
Shimano Ultegra FD-R8000
SHIFTERS
Shimano Ultegra ST-R8020 CarbonDual control 22 Speed
CRANKSET
Shimano Ultegra FC-R8000Hollowtech II 50x34 T
BB-SET
Shimano SM-BB71-41B
CHAIN
Shimano CN-HG601-11
CASSETTE
Shimano CS-R700011-32
BRAKES
Shimano BR-R8070 Hyd.Disc
ROTOR
Shimano SM-RT800 CL rotor 160/F and 160/R
HANDLEBAR
Syncros Creston 2.0 CompactAlloy 31.8mm
H'STEM
Syncros RR2.01 1/8" / four Bolt 31.8mm
SEATPOST
Syncros Duncan 1.027.2/350mm
SEAT
Syncros Tofino Regular 2.0 Channel
HEADSET
Syncros Integrated
WHEELSET
Syncros RP2.0 Disc28 Front / 28 RearSyncros RWS
FRONT TIRE
Schwalbe ONE Fold700x30C
REAR TIRE
Schwalbe ONE Fold700x30C
APPROX WEIGHTS IN KG
8.30
MAX. SYSTEM WEIGHT
120 kgThe overall weight includes the bikethe riderthe equipmentand possible additional luggage.
GEOMETRY
XXS/47
XS/49
S/52
M/54
L/56
XL/58
XXL/61
A
HEAD TUBE ANGLE
70.5 °
71.0 °
72.0 °
72.5 °
73.0 °
73.3 °
73.3 °
B
HEAD TUBE LENGTH
4.5 IN
4.9 IN
5.7 IN
6.5 IN
7.3 IN
8.1 IN
8.9 IN
C
TOP TUBE HORIZONTAL
19.9 IN
20.3 IN
20.9 IN
21.5 IN
22.0 IN
22.6 IN
23.2 IN
D
STANDOVER HEIGHT
28.6 IN
29.2 IN
30.2 IN
31.0 IN
31.8 IN
32.6 IN
33.5 IN
E
BB OFFSET
-2.6 IN
-2.6 IN
-2.6 IN
-2.6 IN
-2.6 IN
-2.6 IN
-2.6 IN
F
BB HEIGHT
11.0 IN
11.0 IN
11.0 IN
11.0 IN
11.0 IN
11.0 IN
11.0 IN
G
WHEEL BASE
38.3 IN
38.6 IN
38.6 IN
38.9 IN
39.0 IN
39.3 IN
39.9 IN
H
BB CENTER TO TOPTUBE CENTER
16.1 IN
16.9 IN
18.1 IN
18.9 IN
19.7 IN
20.5 IN
21.7 IN
I
BB CENTER TO TOP OF SEATTUBE
18.5 IN
19.3 IN
20.5 IN
21.3 IN
22.0 IN
22.8 IN
24.0 IN
J
SEAT ANGLE
75.0 °
75.0 °
74.5 °
74.0 °
73.5 °
73.1 °
73.0 °
K
CHAINSTAY
16.3 IN
16.3 IN
16.3 IN
16.3 IN
16.3 IN
16.3 IN
16.3 IN
L
REACH
14.4 IN
14.7 IN
14.9 IN
15.0 IN
15.1 IN
15.3 IN
15.6 IN
M
STACK
20.3 IN
20.8 IN
21.7 IN
22.5 IN
23.3 IN
24.1 IN
24.2 IN
N
STEM LENGTH
