SCOTT 20" Kid's Scale Bike - Silver

The SCOTT Scale 20 is our truly functional bike for kids who like a race inspired style.Please note that bike specifications are subject to change without prior notice.
SPECIFICATIONS
FRAME
Scale 20 JuniorAlloy 6061 / Semi int. HTSCOTT dropout / V-Brake
FORK
SR Suntour XCT-JR 2040mm travelSofter spring setup
REAR DERAILLEUR
Shimano RD-TY3007 Speed
SHIFTERS
Shimano SL-RS 36-7Revo Shifter
CRANKSET
Prowheel / Alloy Crank 127mm36T / w/CG PVG double cover
BB-SET
Feimin / BB68 / cartridge / square taper
CHAIN
KMC Z7
CASSETTE
SunRace MFM3007 Speed / 13-34T
BRAKE LEVERS
Tektro JL-510 TS / RS
BRAKES
Lee-Chi TX-119LKids specific
HANDLEBAR
Junior Flat-Bar / Alloy540mm / Syncros Youth 100/80 Grip
H'STEM
LEADTEC LCS-713050mm / 25.4mm clamp
SEATPOST
Alloy / 26.8mm / 250mm
SEAT
Syncros Future Pro
HEADSET
Feimin FP-H807, 1 1/8" Semi Int.
HUB (FRONT)
KT-122F / Nutted
HUB (REAR)
KT-122R / Nutted
SPOKES
15g / UCP / black
RIMS
Shining V-6NS
FRONT TIRE
Kenda K1227 Booster / 20x2.2" / 30TPI
REAR TIRE
Kenda K1227 Booster / 20x2.2" / 30TPI
PEDALS
MARWI SP-700 / w/Reflector
EXTRAS
Kickstand
ACCESSORIES
Syncros Stem Protector
APPROX WEIGHTS IN KG
10.60
APPROX WEIGHTS IN LBS
23.37
MAX. SYSTEM WEIGHT
50 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
GEOMETRY
INCHES
20"
A
HEAD TUBE ANGLE
69.0 °
B
HEAD TUBE LENGTH
3.9 IN
C
TOP TUBE HORIZONTAL
17.7 IN
D
STANDOVER HEIGHT
20.1 IN
E
BB OFFSET
F
BB HEIGHT
G
WHEEL BASE
35.1 IN
H
BB CENTER TO TOPTUBE CENTER
I
BB CENTER TO TOP OF SEATTUBE
11.0 IN
J
SEAT ANGLE
70.4 °
K
CHAINSTAY
14.6 IN
L
REACH
M
STACK
N
STEM LENGTH
2.0 IN
0
TRAIL
