SCHWINN 700 M Fastback Carbon 105 Small - Matte Black

Ride smoother, ride lighter, ride longer. Go further and go faster as you explore the open road on the beautiful, smooth, lightweight Fastback Carbon 105 by Schwinn. Designed for advanced to expert riders who want to go farther and faster on a bike built for superior performance.
Lightweight Durability
Schwinn road-tuned carbon frame and Schwinn race carbon fork with carbon tapered steerer provide strength that won't weigh you down. Ideal for paved areas.
Shift Gears Smoothly
22-speed trigger shifters and rear derailleur provide outstanding performance and gearing to meet any challenge with quick, precise gear changes.
Stopping Power
Front and rear caliper brakes deliver precision stopping power and speed control in a variety of conditions so you can ride with confidence.
Ready for the Road
Silicon gel bar tape, race seat, and lightweight aluminum wheels provide extra comfort on long distance rides. Forward riding position offers an athletic, aerodynamic posture.
Technical Specifications
Frame
N LITENED Black Label carbon, 700c road tuned geometry, internal cable routing, 10 mm x 135 mm dropout, replaceable hanger, tapered headtube
Fork
Schwinn carbon race, 700c, carbon tapered steerer, 9 mm x 100 mm QR
Crank
Shimano 105 FC-R7000, 50/34T
Chain
Shimano CN-HG601
Bottom Bracket
Shimano, sealed external bearing, 68 mm
Shifters
Shimano 105 ST-R7000, 22-speed
Front Derailleur
Shimano 105 FD-R7000, 34.9 mm clamp
Rear Derailleur
Shimano 105 RD-R7000
Rims
Shimano WH-RS100, aluminum, double wall, 20H front, 24H rear
Rear Hub
Shimano WH-RS100, aluminum, 10 mm x 130 mm QR, 24H
Spokes
14G, stainless steel
Tires
Kenda Kriterium, 700c x 25c, folding bead
Pedals
Schwinn road, nylon, toe clips and straps
Brakes
Shimano 105 BR-7000, dual pivot caliper, aluminum
Stem
Schwinn, aluminum, threadless, - 7° rise, 31.8 mm clamp
Headset
Threadless, IS42 / IS52, sealed bearings
Seat Post
Aluminum, 300 mm, 16 mm offset, 31.6 mm
Saddle
Schwinn S1 race, steel rails
Grips
Schwinn road, Silicon gel tape
Sizes
700c
Geometry
XS
SM
MD
LG
XL
A
Head Tube Angle (degrees)
70.5
71
72
73
73
B
Seat Tube Angle (degrees)
74
73.5
72.5
72
71.5
C
Horizontal Top Tube Length (mm)
514
533
550
566
587
D
Seat Tube Length (mm)
450
480
510
540
570
E
Standover Height (mm)
712.1
739.2
769.9
801.9
826.6
F
Head Tube Length (mm)
116
138
165
195
215
G
Chainstay Length (mm)
408
410
413
415
417
H
Fork Offset (mm)
45
45
45
45
45
I
Bottom Bracket Drop (mm)
70
70
70
70
70
J
Wheelbase (mm)
974
986
987
990
1006
Stem Length (mm)
90
90
100
100
110
Bar Width (mm)
400
420
420
420
440
Stack (mm)
520
542.6
571.9
604.1
623.3
Reach (mm)
365
372.3
369.6
369.7
378.5
Crank Length (mm)
170
170
172.5
172.5
175
Seat Post Size (mm)
31.6
31.6
31.6
31.6
31.6
