SARK100 1-60 Mhz HF ANT SWR Antenna Analyzer Meter for Ham Radio

Manual Click here to openSpecification Frequency GenerationControl 1 60 MhzSource impedance 50 OhmsStability 100ppmSpectral Purity Harmonics down TBD dB beyond 60 MHzStep Size User configurable increments of 100 Hz 1 kHz 10 kHz and 100 kHzUsable Measurement Range SWR 1 0 to 9 99Impedance approx 5 to 2000 ohmsRF Output Adjustable 2 0 Volts pp typ Power supply Powerd by External 12 to 15 Volts DC 500mAControls Pushbuttons 5 Mode Band Config Scan Up Down Switch Power On Connectors RF Out BNCUSB Mini B receptacleExternal power 2 1mm Power Jack center pin positive Applications Measure antenna electrical parameters SWR impedance resistance reactance capacitance inductanceMeasure feed point impedanceMeasure ground lossAdjust antenna tuners and determine lossMeasure inductors and capacitorsMeasure coax transmission line SWR length speed factor approximate and loss resonant frequency and impedance Measure and determine optimum settings for tuning stubs SWR approximate resonant frequency bandwidth impedanceDetermine characteristic impedance of transmission lineDetermine length and wave phasing linesCoaxial Cable LossDetermine antenna tuner lossMeasure balun lossMeasure inductorEstimate quartz crystal parametersMeasure magnetic loop resonance and SWROperation button definitions Mode selects operation mode impedance default complex impedance capacitance and inducatanceBAND select band from any of the availa
