SANOU K12-125 4 Jaws Independent Chuck 125mm Self Centering Lathe Chuck Tools

Descriptions: SANOU K12-125 4 Jaws Independent Chuck 125mm Self Centering Lathe Chuck Tools Specifications: Material:Hardened Steel Model: K12-125 Max RPM: 3800 r/min Jaw: 4 Jaw High precision: 0.05mm Application: for CNC Drilling Milling Machine Color: Silver Lathe Chuck: Diameter: 125mm(4.921") Thickness: 58mm(2.283") Center Hole: 30mm(1.181") Bolt Circle Diameter: 108mm(4.252") Runout: 0.003" Internal Jaw: Clamping Range A-A1: 2.5- 40mm(0.098"- 1.575") Jamming Range B-B1: 38- 125mm(1.496"- 4.921") External Jaw Clamping Range C-C1: 38- 110mm(1.496"- 4.331") Features: - Short cylindrical center mounting - Model K12 chucks are provided with one-pieces jaws(which include a set of internal jaws and a set of external ones ). - the jaws for K12A, K12C and K12D chucks are composed of two-pieces jaws. They can perfrom as either internal jaws through adjustment - The jaws for K12A and K12D chucks conform to is 03442 standard - Model K12 chucks are supplied with traditional two-pieces jaws. - Function:Four-jaw synchronous movement for clamping four square, square parts, also applies to shaft type, disk parts. - Applicable machine tools and accessories: - General lathe, economical CNC lathes, grinding machines, milling machines, drilling and machine accessories etc. Package Included: 1 Pc x Self-Centering Jaw 4 Pcs x Inside Jaws 4 Pcs x Outside Jawslarge 1 Pc x Safety Chuck Key 3 Pcs x Mounting Bolts More Details:
