Runcam Micro Swift 3 + Mini DVR Remote Control 4:3 600TVL CCD Mini FPV Camera 2.1mm/2.3mm M8 Lens PAL/NTSC OSD Configuration

Runcam Micro Swift 3 + Mini DVR Remote Control 4:3 600TVL CCD Mini FPV Camera 2.1mm/2.3mm M8 Lens PAL/NTSC OSD Configuration Description: Item Name: Micro Swift 3 Image Sensor : 1/3" SONY Super HAD II CCD Horizontal Resolution : 600TVL Lens Dia. : M8 Lens : 2.1mm FOV160 / 2.3mm FOV 145 (optional) Signal System : PAL / NTSC (optional) Integrated OSD : Yes One Key Scene : Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight S/N Ratio :>60dB (AGC OFF) Electronic Shutter Speed : PAL: 1/50~100,000; NTSC: 1/60~100,000 Auto Gain Control (AGC) : Yes Min. Illumination : [email protected] WDR : D-WDR DNR : 2DNR Day/Night : Color/Auto/B&W Remote Control Flight Controllers : BetaFlight 3.3 / ButterFlight 3.4 / Cleanflight 2.2 Power : DC 5-36V Current : 60mA@12V / 120mA@5V Net Weight : 9g(2.3mm) / 11g(2.1mm) Dimensions : L19mm*W19mm*H25mm Features: Support remoting configuration, support BetaFlight 3.3 / ButterFlight 3.4 / Cleanflight 2.2 Wider Lens, brighter image 5 preset scenes parameter can be switched by remote control, OSD information include voltage, time etc. Completely compatible with TX200U transmitter Item name: Mini FPV DVR Module Power in: DC 3.3-5.5V Work Current: 250mA Max Power out: DC 5V @ Max 250mA Video in: CVBS@1Vp-p 75 Video out: CVBS@1Vp-p 75 Encoder: MJPEG@AVI Resolution: VGA(640 x 480) @ 30fps(NTSC)/25fps(PAL) Audio in: MIC Micro SD Card: Max 32G Dimension: 25 x 25mm @20 20 M2 holes Net Weight: 3.5g Remote Control Version Using the Speedy Bee App to set the Remote control function, you can start/stop recording through the remote control. For example, you can bind the recording function to the ARM mode, and the DVR will start recording when the ARM mode is activated. Otherwise, the DVR will stop recording. Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7) Method 2. Manual association Open the App (iOS >= 1.0.8, Android >= 1.0.7)=> select the Help Center=>click RunCam DVR-S => select Telemerty Control Features: * Designed for Mini FPV Racing Drone. ( 25*25mm @ 20*20mm M2 holes) * Lossless video output for VTX. (Since it has been loaded to the DVR, it needs to synchronize the video amplification output) * Black technology. Can record high-frequency vibration motor audio without access to MIC. English Manual, Click Here Package Included: 1x Runcam Mini FPV DVR Module 1 x Runcam Mini Swift 3 M8 Camera 1 x Bracket 1 x 6P FPV Cable 1 x Screw Pack
