RunCam TX200U&Micro Eagle Combo 5.8G 48CH VTX 1/1.8" CMOS 800TVL WDR FPV Camera Transmitter

Click here to download the manual: Manual.pdf T200U User Manual.PDF Specification: Model: RunCam Micro Eagle Image Sensor: 1/1.8" CMOS Sensor Horizontal Resolution: 800TVL FOV : FOV 170 @ 16:9 FOV 140 @ 4:3 Screen Format: 16:9 / 4:3 Switchable on OSD menu Signal System: NTSC / PAL Switchable on OSD menu Mirror/Flip: Yes S/N Ratio: >50dB Electronic Shutter Speed: Auto Max Gain: 1-9 Level Min. Illumination: [email protected] WDR: Level 1-6 available Day/Night: Auto/External/Color/B&W Power: DC 5-36V Current: 200mA@5V / 90mA@12V Housing Material: ABS Net Weight: 8.5g Dimensions: L19mm*W19mm*H22mm TX200U Model RunCam TX200U Frequency Channel 5.8G 48CH Output Power 25mW / 200mW Working Current 5V@150~400mA Voltage out 5V@max 250mA Voltage in 1S 3.5-5.5V Video Input Impedance 75 Ohm Antenna U.FL 5.8G 2dB Omni antenna Weight 2.5g (with antenna) PCB Size 19mm*19mm Features: Mirror & Flip image available 16:9 / 4:3 Switchable on OSD menu NTSC / PAL Switchable on OSD menu Level 1-6 available WDR Package included: 1x Camera 1x Aluminum bracket 1x Set of screws 1x OSD Key-press Board 1x 3pin FPV silicone cable 1x Manual And 1 X TX200U 1 X Set of screws
