RunCam Racer 2 + Mini DVR Remote Control Super WDR CMOS 700TVL 1.8mm/2.1mm fpv Camera 6ms Low Latancy OSD With Selector Switch

RunCam Racer 2 + Mini DVR Remote Control Super WDR CMOS 700TVL 1.8mm/2.1mm fpv Camera 6ms Low Latancy OSD With Selector Switch Description RunCam Racer 2 Camera Model RunCam Racer 2 Image Sensor Super WDR CMOS Sensor Horizontal Resolution 700TVL Lens 1.8mm FOV160 2.1mm FOV 145 Screen Format 4:3 / Widescreen Switchable Signal System NTSC / PAL Switchable Mirror/Flip Available Integrated OSD Yes One Touch Scene Setting Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight S/N Ratio >50dB Electronic Shutter Speed Auto Min. Illumination [email protected] WDR Super WDR Day/Night Auto Menu Control Joystick Control / UART Control Switchable Power DC 5-36V Current 110mA@5V / 40mA@12V Housing Material ABS Net Weight 5.5g Dimensions L19mm*W19mm*H18mm User Manual :https://www.runcam.com/download/Racer2-Manual.pdf?t=20181127 Mini FPV DVR Module Power in: DC 3.3-5.5V Work Current: 250mA Max Power out: DC 5V @ Max 250mA Video in: CVBS@1Vp-p 75 Video out: CVBS@1Vp-p 75 Encoder: MJPEG@AVI Resolution: VGA(640 x 480) @ 30fps(NTSC)/25fps(PAL) Audio in: MIC Micro SD Card: Max 32G Dimension: 25 x 25mm @20 20 M2 holes Net Weight: 3.5g Remote Control Version Using the Speedy Bee App to set the Remote control function, you can start/stop recording through the remote control. For example, you can bind the recording function to the ARM mode, and the DVR will start recording when the ARM mode is activated. Otherwise, the DVR will stop recording. Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7) Method 2. Manual association Open the App (iOS >= 1.0.8, Android >= 1.0.7)=> select the Help Center=>click RunCam DVR-S => select Telemerty Control Features: * Designed for Mini FPV Racing Drone. ( 25*25mm @ 20*20mm M2 holes) * Lossless video output for VTX. (Since it has been loaded to the DVR, it needs to synchronize the video amplification output) * Black technology. Can record high-frequency vibration motor audio without access to MIC. Package Included: 1x Runcam Racer 2 Camere 1x Runcam Mini FPV DVR Module
