RunCam Micro Swift & TX200U Combo 5.8G 48CH VTX 600TVL 2.1mm/2.3mm 1/3 CCD FPV Transmitter Camera Se

Click here to download the manual: Manual.pdf TX200U.PDF Specification: Model: RunCam Micro Swift Image Sensor: 1/3" SONY Super HAD II CCD Horizontal Resolution: 600TVL Lens: 2.1mm Lens(M8) FOV: 160 degree(2.1mm) / 145 degree(2.3mm) Signal System: PAL / NTSC S/N Ratio: >60dB(AGC OFF) Electronic Shutter Speed: PAL:1/50 ~ 100,000; NTSC:1/60 ~ 100,000 AutoGain Control(AGC): YES Back light compensation(BLC): YES Min.illumination: 0.01Lux/1.2F WDR: D-WDR DNR: 2DNR Day/Night: Color / Auto / B&W Power: DC 5 to 36V Net weight: 5.6g Dimensions: 19mm * 19mm * 19mm Model RunCam TX200U Frequency Channel 5.8G 48CH Output Power 25mW / 200mW Working Current 5V@150~400mA Voltage out 5V@max 250mA Voltage in 1S 3.5-5.5V Video Input Impedance 75 Ohm Antenna U.FL 5.8G 2dB Omni antenna Weight 2.5g (with antenna) PCB Size 19mm*19mm Package Included 1 X Camera 1 X 1.25mm 3pin to 1.25mm 3pin FPV silicone cable 1 X 1.25mm 3pin to 1.0mm 3pin FPV silicone cable 1 X TX200U 1 X Set of screws
