Rock64 Media Board Computer 1 2 4 GB Multimedia Development Motherboard With Power Supply Shell Heatsink Kit

ROCK64 HDR Media Board Computer: ROCK64 is a credit card size 4K60P HDR Media Board Computer powered by Rockchip RK3328 Quad-Core ARM Cortex A53 64-Bit Processor and support up to 4GB 1866MHz LPDDR3 memory. It provides eMMC module socket, MicroSD Card slot, Pi-2 Bus, Pi-P5+ Bus, USB 3.0 and many others peripheral devices interface for makers to integrate with sensors and devices. Various Operating System (OS) are made available by open source community such Android 7.1, Debian, Yocto and many more to come. State of software support for the hardware: Requirement GNU/Linux Android/Linux Kodi/Linux 2160p 30Hz 8bit h264/h265/vp8 yes yes UI using GPU no yes Youtube no yes no vp9 / mpeg4 / mpeg2 / 10bit HDR / YCbCr no yes no CPU Architecture: Quad-core Cortex-A53 up to 1.5GHz CPU Full implementation of the ARM architecture v8-A instruction set ARM Neon Advanced SIMD (single instruction, multiple data) support for accelerated media and signal processing computation ARMv8 Cryptography Extensions In-order pipeline with symmetric dual-issue of most instructions Unified system L2 cache Include VFP v3 hardware to support single and double-precision operations Integrated 32KB L1 instruction cache, 32KB L1 data cache with 4-way set associative TrustZone technology support Full CoreSight debug solution One separate power domains for CPU core system to support internal power switch and externally turn on/off based on different application scenario PD_A53: Cortex-A53 + Neon + FPU + L1 I/D Cache of core 2/3 One isolated voltage domain to support DVFS GPU Architecture: ARM Mali-450MP2 Dual-core GPU OpenGL ES 1.1 and 2.0, OpenVG1.1 System Memory: LPDDR3 RAM Memory Variants: 4GB Storage Memory: ROCK64 boards have 128Mb built-in SPI Flash memory but not yet in use, currently use bootable microSD Cards or bootable attachable eMMC. Features: Input Power: +5V @3A with 3.5mm/1.35mm Type H Barrel type DC connector (@2A still work if no heavy loading on USB 3.0 port) Video: HDMI 2.0a output up to 4K@60Hz 4K HDR @ 60fps H.264/AVC Base/Main/High/High10 pr0file @ level 5.1; up to 4Kx2K @ 60fps H.265/HEVC Main/Main10 pr0file @ level 5.1 High-tier; up to 4Kx2K @ 60fps VP9, up to 4Kx2K @ 60fps MPEG-1, ISO/IEC 11172-2, up to 1080P @ 60fps MPEG-2, ISO/IEC 13818-2, SP@ML, MP@HL, up to 1080P @ 60fps MPEG-4, ISO/IEC 14496-2, SP@L0-3, ASP@L0-5, up to 1080P @ 60fps VC-1, SP@ML, MP@HL, AP@L0-3, up to 1080P @ 60fps MVC is supported based on H.264 or H.265, up to 1080P @ 60fps Audio: 3.5mm A/V Jack (Composite Video Output and RCA Stereo support using conversion cable) Network: 10/100/1000Mbps Ethernet WiFi 802.11 b/g/n with bluetooth 4.0 (optional USB dongle) Storage: microSD - bootable, support SDHC and SDXC, storage up to 256GB eMMC - bootable (optional eMMC Module) 1 USB3.0 Dedicated Host port 2 USB2.0 Dedicated Host port (top one is USB-OTG) Expansion Ports: 2x20 pins "Pi2" GPIO Header 2x11 pins "Pi P5+" GPIO Header (with 2nd 10/100Mbps Ethernet pins) More Information please see: http://wiki.pine64.org/index.php/ROCK64_Main_Page Package includes: 1 x ROCK64 Module 1 x Heatsink 1 x Power supply 1 x Shell
