Reprap 3D Printer Accessories Azteeg Control Board Motherboard

Reprap 3D Printer Accessories Azteeg Control Board MotherboardIntroduce Azteeg control board is an open source controller designed to be used in RepRap 3D printers and similar Cartesian based machines including CNCs it has all the features needed to run all current and future single extruder designs The Azteeg is based on Sanguino Sanguinololu and is compatible with mostbased firmware Sprinter Marlin Repetier plus others It is pin to pin compatible with the Sanguinololu with the addition of a FAN PIN The Azteeg features mostly SMT parts to ease production and reduce cost Description Atmel ATMEGA1284P with FT232RL FTDI USB chip ATMEGA 644P on v1 0 RoHS CompliantCompatible with Sprinter Marlin RepetierMosfet control for 1 extruder and 1 hotbedExtra PWM control for small fan or LED3 end stops and 2 thermistor inputs12 30V input high efficiency switching Power supply 500mA maxDedicated SD card female header SDRAMPS compatible Low RDSON Mosfets for less heat buildupInput power selector for micro controller USB or internal regulator Secondary power input for stepper motorsOptional pads for TVS spike suppression diodes for the MosfetsMosfet heatsinks includedI2C TX1 serial 5 GND SPI and ADC pins on the expansion portsFast acting blade fuseBoth right angle and vertical connector sets includedLots of LED RX TX serial PWR hot end and hot bedPackage included 1 x Azteeg control board
