Rcharlance F4 Pro V2 30.5x30.5mm Omnibus F4 Flight Controller OSD BEC AIO 40CH 25/200/600/800mW VTX

Rcharlance F4 Pro V2 30.5x30.5mm Omnibus F4 Flight Controller OSD BEC AIO 40CH 25/200/600/800mW VTX Specification: Brand Name: Rcharlance Model: F4 Pro + V2 Size: 36x36mm Mounting Hole: 30.5 x 30.5mm Net Weight: 13g Omnibus F4 Flight Controller Processor: STM32F405 Gyroscope: MPU6000( reserved external gyroscope interface ) Firmware: BetaFlihgt 3.2.0 OMNIBUSF4SD Input Voltage: 2 - 6s LiPo support BEC Output: 5V 3A Support Receiver: PPM, SBUS, IBUS, DSM2/DSMX Receiver ( UART1 ) - Integrated with OSD, support BF Ground Station adjust OSD Adjust the PID by OSD via remote control Support Dshot Support SmartAudio, adjust the VTX by OSD ( UART3 ) - MicroSD card blackbox - Baro (BMP280) 5.8G 40CH 25/200/600/800mW FPV Transmitter Frequency: 5362 - 5945MHz Video Format: NTSC / PAL Transmitting Power: 25 / 200 / 600 / 800mW switchable Operating Voltage: DC 7 - 24V Output voltage: 5V / 450mA Working Current: 240mA @ 25mW 340mA @ 200mW 520mA @ 600mW 600mA @ 800mW Transmission Distance: 200m @ 25mW 2KM @ 200mW 4KM @ 600mW 6KM @ 800mW Remote Software protocol: SmartAudio V2.0 Audio Bandwidth: 6.5MHz Video Bandwidth: 18MHz Channel: 40CH Range: Up to 4km omnidirectional RHCP antenna Connector: MMCX Frequency Table: Channel 1 2 3 4 5 6 7 8 Band A 5865 5845 5825 5805 5785 5765 5745 5725 Band B 5733 5752 5771 5790 5809 5828 5847 5866 Band E 5705 5685 5665 5645 5885 5905 5925 5945 Airwire 5740 5760 5780 5800 5820 5840 5860 5880 Race Band 5658 5695 5732 5769 5806 5843 5880 5917 LowRace Band 5621 5584 5547 5510 5473 5436 5399 5362 Features: - Standard 30.5x30.5mm Mounting Hole - Flight Controller AIO FPV Transmitter Module - Integrates pneumatic module, SD card slot - Can upgrade 32K gyroscope - Can use the remote control to set the video transmitter Package Included: 1x F4 Pro V2 Flight Controller AIO VTX Board 1x MMCX to RP-SMA Female 4x Cable
