Raspberry Pi Pico 2 RP2350 USB A Development Board RP2350A RP2350-USB-A RP2350-USB-A-H

Specification 1 It uses the RP2350A microcontroller chip designed by Raspberry Pi 2 The unique dual core and dual architecture is equipped with a dual core ARM Cortex M33 processor and a dual core Hazard 3 RISC V processor with a clock running frequency of up to 150MHz 3 Built in 520KB SRAM and 2MB on chip Flash 4 Using the Type C interface it keeps up with the trend of the times and does not need to worry about whether to insert it in the right or wrong direction 5 The stamp hole design can be directly welded and integrated into the baseboard designed by the user 6 USB1 1 host and device support 7 Onboard 1 USB expansion port compatible with USB2 0 1 1 transmission 8 Support low power sleep and hibernation modes 9 Can be identified as a large capacity storage device through USB for drag and drop downloading 10 RP2350A s 15 GPIO pins are brought out 11 2 SPI 2 I2C 2 UART 4 12 bit ADC and 14 controllable PWM channels 12 Accurate on chip clocks and timers 13 Built in temperature sensor 14 On chip accelerated floating point library 15 12 programmable I O PIO state machines for custom peripheral support Package Included 1 x Raspberry Pi Pico 2 RP2350 USB A Development Board
