Raspberry Pi 5 PCIe to M.2 E Key Adapter Board with PoE Support 25W 5V 12V Output WiFi 7 6 AX210 AX200 BE200 Bluetooth U

Specification Product Name PCIe to M 2 E Key Expansion BoardPoE power input 37V 57V DC inputPower output GPIO pin header 5V 4 5A MAX 2P pin header 12V 2A MAX Product size 56 0 x85 0 mm Network standard Support IEEE 802 3af at PoEPCle interface type M 2 E KeyFeatures 1 It can be connected to PI5 via a 16PIN cable It is based on the Raspberry Pi 40PIN GPIO interface design and the pin header is led out on the top which is convenient for connecting to other Raspberry Pi expansion boards 2 Supports PoE Ethernet power supply Only one network cable is needed to connect to the PoE device to enable the Raspberry Pi to connect to the Internet and power it 3 Onboard multiple power supply interfaces onboard 5V and 12V pin header power supply interfaces and the total output power of the 5V interface is up to 4 5A the total output of 12V and 5V does not exceed 25W which can meet the power supply of the Raspberry Pi and other devices 4 Onboard SMA internal antenna interface supports USB bluetooth connection and the bluetooth signal can be input to the Raspberry Pi through the USB adapter board 5 Applicable to Raspberry Pi 5 support NGFF M 2 E Key wireless network card Package Includes 1x PoE M 2 E KEY HAT Board1x USB Type C Adapter EU 2x IPEX 1 Gen to IPEX 4 Gen 6cm 1x 16P Cable 40mm1x Screws PackNote The other items are not includes for reference only
