Radiolink R12DS 2.4G 12CH FHSS DSSS Spread Spectrum Dual Antenna Receiver

Working Mode 1 PWM signal output working mode red LED indicates PWM signal output 11 channels Totally 2 S BUS signal output working mode blue purple LED indicates S BUS signal output 12 channels totally S BUS and PWM signal working at the same time S BUS signal channel 3 pin of row 11 output 12 channels S BUS signal PWM signal channels 3 pin of row 1 to row 10 output CH3 to CH12 PWM signals but 12 channel in total How many PWM signal channels you can use depends on how many S BUS signal channels you have used e g you have use 4 S BUS signal channels then you have 8 PWM signal channels to use PWM signal working mode S BUS signal working mode Description Brand Name RadiolinkItem Name R12DS 2 4G 12CH Dual Antenna ReceiverChannels 12 channels output 12 channels signal support S BUS and PWM signal output synchronously Working voltage 4 8 10VWorking current 38 45mA input voltage 5V Size 50 31 5 14 5 MMWeight 14gReceiver integrate telemetry sensor including signal strength and voltage Support extended engine voltage telemetry module PRM 01 and module PRM 02 can feedback GPS info Speed voltage etc on AT9 AT9S AT10 AT10II display when work with flight controller APM or PIX Resolution 4096 section precision 0 25us per section servo anti shake rudder Control distance about 4 kilometers air Maximum range tested in unobstructed areas free of interference and may vary depending on local regulations Note 1 Put the transmitter and the receiver close to each othe
