Racerstar 2430 Sensorless Waterproof Motor 7200/5800KV 25A ESC For 1/18 1/20 Cars

Racerstar 2430 Sensorless Waterproof Motor 7200/5800KV 25A ESC For 1/18 1/20 Cars Description: Motor Features: - 4 pole 12 slot hi-torque motor design - CNC machined 6061 T6 billet aluminum heatsink can - High purity copper windings maximizes efficiency - High RPM ABEC 5 oversized bearings - Universal fit, fits all 1/16, 1/18, 1/20 brushless cars; multi-mounting system for M2.5 screws - Precision balanced rotor, smoothness for best reliability and maxium RPM - Stator- super thin (0.35mm) laminations - Removalbe/replaceable rotor - Precision engineered for maxium energy coversion Motor Specification: Product Watts Max Voltage Max Amps Rotor Poles IO Resistance KV (RPM/Volt) Max RPM Length Diameters Weight (g) Shaft (mm) Length of Extend Shaft Connector 2430 200 8.4V 24A 4 2.3A 0.007 7200 60000 30mm 24mm 58 2 12mm 3.5mm gold 2430 200 10.8V 18A 4 1.9A 0.013 5800 60000 30mm 24mm 58 2 12mm 3.5mm gold ESC Features: - Specially desighed for RC car with excellent start-up, acceleration and linearity feartures - Compatible with sensorless brushless motor - The strong resistant current capability, excellent heat dissipation - Multiple protection features: low voltage cut-off protection for lithium or nickel battery / over-heat protection / throtttle signal loss protection / motor blocked protection - Easily programmed and compatible with pocket-sized program card ESC Specifications: Model 25A Cont. Current / Burst Current 25A / 100A Motor Type Sensorless Brushless Motor Suitable Car 1/18, 1/16 Suitable Brushless Motor 12T Resistance 0.004ohm Battery 2 cells Lipo 4-6 cells NiMH BEC Output 5V/2A (analog mode) Dimension 25*30*14.5mm If you want to upgrade WLtoys 1/18 cars and FS Racing 73902 1/18 Brushed Buggy, you may need battery(Product ID: 914720) please click here; battery (Product ID: 1052678) please click here. For ESC program card, please click Package Included: 1 X Motor 1 X ESC 2 X Instruction
