RR8503.03D Universal LCD TV Controller Driver Board TV Motherboard

Firmware: http://myosuploads3.banggood.com/products/20190407/20190407213215RR8503.03D.rar Introduction: RR83.03D is a multi-purpose and energy-efficient LCDTV control board with single/dual 8bit LVDS the resolution of LCDTV panel is up to 1920*1080. RR83.03D supports analog TV front-end (PAL/SECAM/NTSC) demodulator. HDMI,USB,PC-RGB, Earphone output, AV video and audio input an audio amplifier which supports 2*3W(4ohm)/ 2*1.5W(8ohm) outputs is built in. RR83.03D Software upgrade and multimedia playback function are applicable with the USB slot. Description: Support Language: Russian, English, Chinese, French, German, Italian, Burmese Scheme of the chip: 8503C Input Interface: PC / HDMI / TV / USB multimedia playing Voltage: DC 12 V 3-5A, 4A is the best Screen interface: LVDS Single 6 / 8 Double 6 / 8 Screen voltage: 3.3V / 5V / 12V Resolution: Support high screen 1920 * 1080, 7-55 inch LVDS screen Chipset RDA8503 OSD Language English/Chinese/ French/Spanish/Portuguese LCD Panel Type TFT-LCD, LED backlight LCD Resolution up to 1920*1080 Interface single/dual 8bit LVDS Panel power 3.3V,5V,12V optional FR input ATV Receiving Range 48.25MHz~865.25MHz Input Impedance 75 ohm Video System PAL,SECAM,NTSC Sound System BG,DK,M,N,L/L' Max Storage 200 channels Video input AV Video System PAL/NTSC/SECAM Video Level 1.0 Vp-p +- 5% Component 480i,480p,576i,576p,720p,1080i,1080p HDMI 480i,480p,576i,576p,720p,1080i,1080p PC-RGB up to 1920*1080@60Hz USB2.0 Multimedia playback and software upgrade Audio Input PC-RGB Earphone Input 0.2 - 2.0 Vrms AV L/R RCA Input 0.2 - 2.0 Vrms Audio Output Max Output Power 2*3W(4ohm) EARPHONE 2*10mW(32ohm)(max) Key Function POWER,INPUT,MENU,CH+,CH-,VOL+,VOL- Power Input DC12V Power Management Standby Power Consumption
