RF Nano V3.0 Micro USB Module ATmega328P QFN32 5V 16M CH340 Integrate NRF24l01+2.4G Wireless Imme

Feature 1 Creative products RF Nano Board Upgraded nano board for The main chip is ATMEGA328P MU QFN32 the latest bootloader IDE 1 8 8 was burned down It is fully compatible with the common nano board RF Nano Board is PIN PIN with Nano V3 0 and share the same codes 2 More convenient for application The RF Nano Board integrates an NRF24L01 module with nano v3 0 board which is very convenient for 2 4G wireless connect application 3 High quality material and Technology We used high quality PCB original material and Immersion Gold Technology to make sure every board has smooth edge and more reliable 4 Super small volume design more convenient to use The PCB size is only 48mm 19mm the pin is fully compatible with Nano V3 0 No Soldering needed The micro usb port is more convenient to use 5 RF Nano Board using CH340 chip to UART you can download mac windows Linux three system drivers Specification Microcontroller ATmega328PNrf24L01 2 4G wirelessArchitecture AVROperating Voltage 5 VFlash Memory 32 KB of which 2 KB used by bootloaderSRAM 2 KBClock Speed 16 MHzAnalog I O Pins 8EEPROM 1 KBDC Current per I O Pins 40 mA I O Pins Input Voltage 7 12 VDigital I O Pins 22PWM Output 6Power Consumption 19 mAWeight 9gParameter ◆ It is fully compatible with the nano v3 0 pin and its usage method◆ BLE chip TI CC2540◆ Work channel 2 4G◆ Transmission distance 50m◆ Supports AT directive to configure BLE◆ Support USB virtual serial port hardware serial p
