RF Module Ham Low Power RF Module 32 DB Gain Microwave Large Area Heat Dissipation For TV Audio

RF Module Ham Low Power RF Module 32 DB Gain Microwave Large Area Heat Dissipation for TV Audio Specification: Item Type: RF Module Material: PCB Operating Frequency: 0.1-3000MHz Working Voltage: 9-12V Working Current: 27mA Amplification Gain: 32dBtyp. F=0.1MHz gain=32dB F=500Mhz gain=32dB F=1000MHz gain=32dB F=1500Mhz gain=32dB F=2000MHz gain=32dB F=2500MHz gain=30dB F=3000MHz gain=29dB Maximum Output: 13dBm 20mW System Impedance: 50ohms Connector Model: SMA K RF In: Input signal amplification RF Out: Output amplified signal VCC: Positive power supply suitable for lithium batteries GND: Negative power supply Package List: 1 x RF Module Note: Pay attention to the correct operation.
