RF Microwave DC Bias DC Block DC Feed DC Bias 0.2-180MHz Module

Use 1 RF power supply for active antenna2 The output of the broadband amplifier is blocked3 Communication data is injected through the RF end4 Imported high frequency and low loss magnetic ringWorking parameters 1 Frequency range 0 2 180MHz2 Insertion loss 0 1dB 1MHz 0 4dB 100MHz3 Maximum voltage 30V4 Maximum current 3A5 Radio frequency connector SMA K outer screw inner hole 6 System impedance 50 ohm7 Dimensions 33mmx33mm without connectors8 Product appearance size length 112mm width 84mm height 25mm9 Product weight 16 5gWiring 1 DC External DC power supply2 RF RF signal terminal this port can only transmit RF signals 3 RF DC RF DC bias this port can transmit RF and DC bias 4 GND common ground terminal for DC power supply5 VCC the power supply terminal of DC power supplyPackage includes 1 x Module
