RF Coaxial Connector Fourth Generation IPX Male to SMA Female Connector Load 50 Ohm For FPV RC Drone

RF Coaxial Connector Fourth Generation IPX Male to SMA Female Connector Load 50 Ohm For FPV RC DroneDescription Item name RF Coaxial ConnectorTemperature range 65 to 165 C PE Cable 40 to 85 C Vibration MIL STD 202 Method 213Characteristic impedance 50Frequency range DC 12 4GHz semi rigid cable 0 18GHz Operating voltage 335V max effective value Withstand voltage 1000V rms minimum sea level Contact resistance 3 m between inner conductors 2 m between outer conductorsInsulation resistance 5000MInsertion loss 0 15 dB 6GHzVoltage standing wave ratio straight flexible cable 1 10 0 002fSemi rigid cable 1 05 0 001fCurved flexible cable 1 20 0 003fSemi rigid cable 1 10 0 001fDurability 500 cyclesFeatures Housing brass plated hard gold Pin brass plated hard gold Jack berylliumbronze plated hard gold Elastic contact piece beryllium bronze plated hard gold Insulator PTFE Crimp sleeve copper alloy nickel plated or gold plated O type seal silicone rubber 6146Package Included 1xRF Coaxial Connector Fourth Generation IPX Male to SMA Female Connector
