RF And Microwave DC Bias DC Feeder Module 10-6000MHz

Use 1 RF power supply of active antenna2 The output of the broadband amplifier is straight3 communication data injected through the RF side Working parameters 1 Frequency range 10 6000MHz2 Insertion loss 0 3dB 512MHz 0 45dB 1575MHz3 Maximum voltage 50V4 Maximum current 500mA5 RF connector SMA K outer screw bore 6 System impedance 50 ohms7 Dimensions 33mmx33mm without connector Wiring 1 DC external DC power supply2 RF RF signal port this port can only transmit RF signals 3 RF DC RF dc bias this port can transmit RF and dc bias 4 GND DC powered common ground5 VCC DC power supplyPackage included 1 x RF And Microwave DC Bias DC Feeder Module 10 6000MHz
