RANMEI Manometer 1.5\ （50.5mm）OD Tri Clamp Membrane Pressure Gauge-SS304 Diaphragm Gauge

Feature *YTP60 sanitary diaphragm pressure gauge range can be made in various specifications 0.1MPa~0-6MPa the diaphragm drives the spring tube indicating the pressure value *The shell is made of 304 stainless steel and the diaphragm is made of 316L stainless steel which has the characteristics of wear resistance and corrosion resistance and has good contact performance. * It has the advantages of quick and convenient assembly and disassembly easy to clean not easy to pollute clean and beautiful safe and reliable etc. * Can be widely used in pharmaceutical food beverage cheese water treatment and other industries. *Cut off the top oil plug when in use to improve the accuracy of product pressure. (Only applicable to small measuring range below 0.6MPa) Specification Product Name: Sanitary Diaphragm Pressure Gauge Item model number: YTP60 Accuracy: Class 2.5 Nominal diameter: 60MM Ambient temperature: -40~70℃ Product material: 304 Whether shockproof: yes Connection method: clamp type conventional size 50.5mm Range: 0.1 0.16 0.25 0.4 0.6 1 1.6 2.5 4 6MPa Packing list: 1*pressure gauge
