RANMEI Ilter Module Adapter Components Electronic Equipment Green 433MHZ 50dbc

Function: Several low-pass filters are compared. Under the condition of the same order elliptic filter the filter can obtain smaller transition bandwidth and narrower stopband fluctuation than Butterworth filter and Chebyshev filter. In this regard the elliptic filter is the best. This is a low-pass filter with 7th order elliptic function. The steepness of the filter is better than that of the filter. Features: 1. The low-pass filter passes the signal below the cut-off frequency but the signal above the cut-off frequency is weakened. 2. Harmonic suppression is often used in electromagnetic signals or placed at the back end of the mixer to filter out high-frequency noise and play a frequency selective role. 3. The filter can greatly weaken the signal of 470m and above and the harmonic suppression ability is about 50dbc. Specification parameters: 1. S11 < - 20dB standing wave ratio SWR < 1.22; 2. 2 < - 20dB standing wave ratio SWR < 1.22; 3. 1 > - 0.5dB insertion loss < 0.5dB; 4. Overall dimension of PCB (without SMA connector): 36mm × 16mm Packing list: Low pass filter module*1
