RANMEI DC 10-55V MAX 60A PWM Motor Speed Controller CW CCW Reversible 12V 24V 36V

Features: *Input supply voltage: DC 10V-55V; Maximum current: 60A; Continuous current: 40A; Speed range: 0- ; Control frequency: 15KHZ; Apply to: DC Brush Motor *The PWM DC motor speed controller come with switch function. High power speed controller switch which is much more adaptable and conveniently change the motor direction. *The enclosure of the speed controller for motor is an aluminum enclosure. Aluminum shell is very strong to prevent damage holes on its side and top which are helpful for heat dissipation. *The stepless motor controller has a simple potentiometer knob adjusts the motor speed from 0% ~ smoothly. And with LED display is accurate to show 0 ~ of the motor speed. The input voltage of PWM motor speed controller should be equal to the rated voltage of the motor within 10-55V or it will be burnt. *The dc motor driver can be used to brush motor speed regulation light dimming regulation in the DC circuit.Note: The motor cannot be used in electric vehicles. Specifications: Input voltage: DC 10-55V Maximum instantaneous current: 60A Continuous current: 40A Duty Cycle adjustable: 0- PWM frequency: 15Khz Regulation type: Potentiometer(switch) With CW/CCW switch Dimension: 110mm * 78mm * 38mm / 4.33 * 3.07 * 1.50 This controller be used for Brushed motor Display type : digital LED(The screen is displayed as 0-100 the percentage of motor speed not the actual speed ) Package Included: 1PCS PWM Motor Speed Controller
