RANMEI 150W DC-DC 10-32V 6A Adjustable Step Up Boost Power Supply Converter Module

Scope of application 1) DIY an output adjustable car power supply you only need to connect your 12V power supply to the input you can freely and continuously adjust the output voltage (14-35V) but the output voltage cannot be lower than the input voltage. 2) Car notebook power supply. The input is connected to your 12V power supply and the output is adjusted to the voltage of your notebook to work. 3) Boost charger you can use 12V power supply to charge batteries higher than 12V such as 24V batteries. 4) To supply power to your electronic equipment as long as the voltage is adjusted to the voltage you need and the current does not exceed the rated current it can work normally. 5) The power supply of the front stage of the system when you are working on a project and the input is 10-18V and your system board needs about 24V power supply and its power is very large the power of ordinary DC-DC modules is too small it can work directly on the machine without debugging and it is easy to achieve high-power boost. Disclaimer: The output power of this module is affected by various factors such as the pre-stage power supply and post-stage load in addition to the load capacity of the module itself; the following data are the results measured by professional equipment and other factors are not considered. The power module is a kind of electronic components please purchase it carefully if you do not have electronic professional knowledge. Specification Module nature: non-isolated boost module Module size: length 65MM* height 23MM* (width 56.5MM including heat sink) Input mode: IN+ input positive level IN- input negative Output mode: OUT+ output positive level OUT- output negative Wiring method: no soldering terminal Input voltage: 10-32V Output voltage: (1) Continuously adjustable (12-35V) The default delivery voltage of our store is 19V Output current: 6A(MAX) Input current: 10A (MAX) (please strengthen heat dissipation if it exceeds 10A) Output power: natural cooling 100W (MAX) plus fan 150W (MAX) Easily drive 65W 90W laptops including dual-core 12V batteries with ordinary 19V 3.42A laptops the module temperature is about 45 degrees Conversion efficiency: 94% (measured when inputting 16V and outputting 19V 2.) (for reference only) Working temperature: industrial grade (-40℃ to +85℃) (if the ambient temperature exceeds 40℃ please reduce the power to use or add a fan) Full load temperature rise: 45℃ No-load current: typical 25mA Short circuit protection: none (please add an overcurrent protector to the input) Input reverse polarity protection: none two tubes are connected in series at the input Packing list: 1*Boost Module
