R502-A Capacitive Fingerprint Reader Module Sensor Scanner Small Thin Circular Ring LED Control DC3.3V MX1.0-6pin

Manual Click here to openFeatures 1 Integrated image collecting and algorithm chip together ALL in One2 The flexibility to adapt to the conditions was the fingers whether it is dry fingers wet fingers light texture fingerprints fingers and old fingers all have high recognition rate 3 The main application areas can be embedded into a variety of end products such as access control attendance safety deposit box4 The R502 A has circular ring indicator light that can be controlled by command Specifications ModelR502 ATypeCapacitive Fingerprint ModuleInterfaceUART TTL Resolution508 DPIVoltageDC 3 3VFingerprint Capacity200Sensing array192 192 pixelWorking current20mAStandby currentTypical touch standby voltage 3 3V Average current 2uAFingerprint module external sizeDiameter 22 mm Fingerprint module inner sizeDiameter 19 3 mm Fingerprint module height5 mm Except the connector Effective collection areaDiameter 15 5 mm ConnectorMX1 0 6PinLED ControlYESLED ColorPurple and Blue and RedScanning Speed 0 2 secondVerification Speed 0 3 secondMatching Method1 1 1 NFRR≤1 FAR≤0 001 Work environment 20C 60CWork Humidity10 85 Anti static capacity15KVAbrasive resistance intensity1 million timesCommunications baud rate UART 9600 N bps where N 1 12 default N 6 ie 57600bps Provide Free Reference SDK Files for Arduino Android Net Windows and so on Provide User Manual Package Included 1 x R502 A Capacitive Fingerprint Module Sensor ScannerModelR501R502R502
