R301T Capacitive Fingerprint Reader Access Control Module Sensor Scanner Fingerprint Touch Function for Android Linux Wi

Manual Click here to openFeatures R301T which added fingerprint touch function 1 Integrated image collecting and algorithm chip together ALL in One2 The flexibility to adapt to the conditions was the fingers whether it is dry fingers wet fingers light texture fingerprints fingers and old fingers all have high recognition rate3 The main application areas can be embedded into a variety of end products such as access control attendance safety deposit box4 Provide Free Reference SDK Files for Arduino Android Net Windows and so on We don t provide technical support for development 5 Provide User ManualSpecifications ModelR301TTypeCapacitive Fingerprint ModuleInterfaceUSB UART RS232 TTL Resolution508 DPIVoltageDC 4 2 6VFingerprint Capacity3000Sensing array192 192 pixelFingerprint module size33 4 20 4 1 0 mm Effective collection area10 10 mm Scanning Speed 0 2 secondVerification Speed 0 3 secondMatching Method1 1 1 NFRR≤0 1 FAR≤0 001 Work environment 20C 50CWork Humidity10 85 Anti static capacity15KVAbrasive resistance intensity1 million timesCommunications baud rate UART 9600 N bps where N 1 12 default N 6 ie 57600bps Package Incldued 1 x R301T Capacitive Fingerprint Reader Access Control Module1 x Connect CableModelR300R301TR302R303R303TR304R306R311R305R307R308Size33 4 20 4 1 0mm33 4 20 4 1 0mm33 4 20 4 1 0mm33 4 20 4 1 0mm33 4 20 4 1 0mm33 4 20 4 1 0mm33 4 20 4 1 0mm35 23 1 5mm55 32 21 5mm52 20 22mm55 5 20 5 21mmInterfaceUARTUSB UARTUSB UART
