Puxing PX-820 VHF, IP67, DMR + Analog, радиостанция

Профессиональная портативная аналогово-цифровая радиостанция Puxing PX-820 UHF.
Режим работы: Цифровой DMR (AMBE+2), Аналоговый ЧМ
Диапазон рабочих частот: 136-174 МГц
Кол-во программируемых каналов: 1000
Выходная мощность: 5/1 Вт
Ёмкость аккумулятора: 1800 мАч, Литий
Степень пыле-влагозащиты: IP67
Ниже приведено оригинальное описание с сайта производителя:
General
Frequency Range
136-174MHz /400-470MHz /customized
Channel Capacity
1000/customized
antenna impedance
50Ω
Operating Voltage
7.4V DC
Operating Temperature
-30°C +60°C
store temperature
-40°C +85°C
Battery Life in 5/5/90 operating mode
1700mAh standard Li-ion battery
analog:10hours,digital:14hours
dust-protection and water resistant
IP67
Size not including antenna
113.5mm×54mm×33.5mm
Weight with battery, antenna
270G
Transmitter
channel spacing
12.5khz
frequency stability
+/-1ppm
Output Power
low power:1W high power:4w
hum and noise
-40dB at F1512.5khz
conducted,radiated spurious emission
-36dBm at <1Ghz,-30dBm at>1Ghz
adjacent channel power
-60dB at 12.5khz
ajacent transient channel power
-50dB@ 12.5KHZ
FM modulation mode
12.5khz:11K0F3E
4FSK digital mode
12.5khz(data only):7K60FXD 12.5khz(data+voice):7K60FXE
modulation maximum deviation
[email protected]
nonactive slot power
-57dBm
audio response
+1dB--3dB
audio distortion
3%(type)
digital protocol
ETSI TS 102 361-1,-2,-3
vocoder type
AMBE+2TM
Receiver
channel spacing
12.5khz
frequency stability
+/-1ppm
analog sensitivity
0.35μV/-116dBm(20dB SINAD)0.22μV/-120dBm(type)
digital sensitivity
0.3μV/-117.4dBm(BER 5%)0.7μV/-110dBm(BER1%)
intermodulation
TIA603C:70dB ETSI:65dB
Adjacent Channel Selectivity
TIA603C:[email protected] ETSI:[email protected]
co-channel rejection
[email protected]
spurious response rejection
TIA603C:75dB ETSI:70dB
conducted spurious emission
-57dBm@<1GHz,-47dBm@>1GHz
blocking
84dB
rated audio power
1w
audio response
+1dB--3dB
rated audio distortion
3%(type)
