Promo Pressure Switch 20bar Nautilus XMLA20A2S11 Telemecanique Schneider Murah

Pressure Switch Nautilus XMLA20A2S11 Telemecanique Schneider
Pressure switch XMLA 20 bar - fixed scale 1 threshold - 1 C/O
KarakteristikDokumenDimensions DrawingsConnections and SchemaPerformance Curves
Mainrange of product
OsiSense XM
product or component type
Electromechanical pressure sensor
pressure sensor type
Electromechanical pressure sensor
device short name
XMLA
pressure rating
20 bar
controlled fluid
Air (0…70 °C)
Fresh water (0…70 °C)
Hydraulic oil (0…70 °C)
fluid connection type
G 1/4 (female) conforming to ISO 228
electrical connection
Screw-clamps terminals, 1 x 0.5...2 x 2.5 mm²
1 connector ISO M20
AWG gauge
AWG 20...AWG 14
cable entry
Cable gland 7…13 mm
s type and composition
1 C/O
product specific application
-
pressure switch type of operation
Detection of 1 single threshold
electrical circuit type
Control circuit
scale type
Fixed differential
local display
With
adjustable range of switching point on rising pressure
1…20 bar
adjustable range of switching point on falling pressure
0.6…19 bar
maximum permissible accidental pressure
45 bar
destruction pressure
90 bar
pressure actuator
Diaphragm
materials in with fluid
Brass
Nitrile
Zinc alloy
enclosure material
Zinc alloy
