Pro Co Sound AVP1V Audio-Visual Interface Wallplate, Black

The Pro Co Sound AVP1V Audio Visual Black Interface Wallplate allows the line or speaker-level outputs of movie projectors, audio and video tape/cassette recorders, phonographs, etc. to be connected to microphone inputs of house P.A. systems. The AVP1V provides audio interfacing and isolation with wide frequency response and low distortion. The AVP1V provides a 1/4" phone jack input for movie projectors and similar monaural A/V equipment. This input allows the AVP1V to be safely connected to the speaker outputs of older tube-type equipment: a 16-ohm, 5-watt load resistor simulates the speaker impedance to prevent damage to the amplifier output stage, while a high- frequency filter reduces hiss from noisy electronics. The AVP1V also features a 10kW linear input level control with a 0 to 10 calibrated knob. Left and right RCA phono jack Line Input puts are resistively mixed to monaural, a handy feature for use with CD players and cassette recorders. (They can also be used as recording outputs for whatever is connected to the Speaker Input Jack). The DBT-1 transformer provides a floating 150-ohm output to an easy-to-use screw-type barrier strip (requiring no crimp- on terminals) for fast wiring installation. The Hum Cancel switch eliminates hum and buzz from AC ground loops between equipment. For further versatility of operation, there is also an independent low-impedance microphone input via a female XLR-type connector wired to the output barrier strip. The AVP1V is built on a standard stainless steel or black anodized aluminum wall plate designed for mounting in any standard two-gang masonry box. With its lustrous brushed finish and laser engraved legends, the AVP1V is both functional and attractive, complementing a wide variety of decors.
