PoE HAT IEEE802.3af 5V 2.5A Output Power Over Ethernet Expansion Board + Cooling Fan for Raspberry Pi 3 Model B+(Plus)

Overview The Raspberry Pi PoE HAT is an add on board for the Raspberry Pi 3 Model B It allows the Raspberry Pi to be powered via a power enabled Ethernet network Features 802 3af PoEFully isolated switched mode power supply3656V DC Class 2 device5V 2 5A DC output25mm x 25mm brushless fan for processor coolingTemperature controlled fan Compliance The Raspberry Pi PoE HAT has undergone extensive compliance testing and meets the following European standards Electromagnetic Compatibility Directive EMC 2014 30 EURestriction of Hazardous Substances RoHS Directive 2011 65 EU GETTING STARTED The Raspberry Pi Power over Ethernet HAT is a small accessory for the Raspberry Pi computer It can only be used with the Raspberry Pi 3 Model B launched March 2018 The PoE HAT allows you to power your Raspberry Pi using Power over Ethernetenabled networks for this product to be used the network it is connected to needs to have power sourcing equipment installed Supplied with this product Raspberry Pi PoE HATMechanical spacersOther hardware needed A Raspberry Pi 3 Model B An Ethernet cablePower sourcing equipment for a 802 3af Power over Ethernet networkConnecting your PoE HAT to the Raspberry Pi Before installing the PoE HAT you must attach the supplied spacers in the four corners of the boardThen connect the Raspberry Pi PoE HAT to the two 0 1 headers 40 4 that are fitted on the Raspberry PiOnce the PoE HAT board is connected you can power the Raspberry Pi through its RJ45
