Pneumatic Manifold Block Splitter Manifolds Air Distribution Blocks Aluminum For Automation Equipment AL-2 AL-3 AL-4 AL-5 AL-6 AL-7 AL-8

Pneumatic Manifold Block Splitter Manifolds Air Distribution Blocks Aluminum For Automation Equipment AL-2 AL-3 AL-4 AL-5 AL-6 AL-7 AL-8
sku: 1803959211
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$8.32
Shipping from: United States
   Description
Pneumatic Manifold Block Splitter Manifolds Air Distribution Blocks Aluminum for Automation Equipment AL-2 AL-3 AL-4 AL-5 AL-6 AL-7 AL-8 Specification: Item Type: Pneumatic Manifold Block Splitter Material: Aluminum Pressure Resistance: 1.0MPA 10kgf/cm Working Pressure: 0~0.9Mpa0~0.92kfg/cm² Adaptation Temperature: 0~60 degrees Celsius Model Total Length Approx. Way Number Holes Number Length x Width Approx. Thread Specifications Intersection Center SpacingApprox. AL-2 65mm / 2.56in 2 Way 5 Holes 20x20mm / 0.80x0.80in G1/412mm 30mm / 1.18in AL-3 95mm / 3.74in 3 Way 6 Holes 20x20mm / 0.80x0.80in AL-4 125mm / 4.92in 4 Way 7 Holes 20x20mm / 0.80x0.80in AL-5 155mm / 6.10in 5 Way 8 Holes 20x20mm / 0.80x0.80in AL-6 185mm / 7.28in 6 Way 9 Holes 20x20mm / 0.80x0.80in AL-7 215mm / 8.46in 7 Way 10 Holes 20x20mm / 0.80x0.80in AL-8 245mm / 9.65in 8 Way 11 Holes 20x20mm / 0.80x0.80in Package List: 1 x Pneumatic Manifold Block Splitter Note: 1. Do not unplug and insert the gas pipe frequently during the use of the connector which will affect the service life of the connector and gas pipe 2. The pipe inserted into the joint needs to be inserted to the bottom of the joint to avoid the possibility of air leakage 3. When pulling out the gas pipe first confirm that there is no pressure in the tube press the end of the joint to the end and pull out the gas pipe
