Pin Plunger Switch Sealed Limit Switch High Toughness Strong Sealing Performance NO+NC 250VAC Reliable For Car Parks
Pin Plunger Switch Sealed Limit Switch High Toughness Strong Sealing Performance NO+NC 250VAC Reliable for Car Parks Specification: Item Type: Sealed Limit Switch Material: PP flame retardant brass Non inductive loads Resistive loads NC 10 NO Lamp loads NC 2.5 NO 1.25 Inductive loads Inductive loads NC 10 NO Motor loads NC 3 NO 1.5 OF Maximum: 600 g / 21.16 ozapprox. RF Minimum: 100 g / 3.53 ozapprox. PT Maximum: 2mm / 0.08in OT Minimum: 5mm / 0.2in MD Maximum: 0.8mm / 0.03in OP mm: 44±1.2 FP: \Operating Speed: 0.01mm to 50cm/sec locking plug type Operation Frequency: Mechanical: 120 times/min Electrical: 30 times/min Contact Resistance: 15m Ohm or less initially Insulation Resistance: 100m Ohm or more below 500VDC Dielectric Strength: 1 000VAC 50/60Hz for 1 minute between non continuous terminals 1 500VAC 50/60Hz for 1 minute between current carrying and non current carrying parts 1 500VAC 50/60Hz for 1 minute between terminals and earth Vibration: Misfire Endurance: 10 to 55 Hz 1.5 mm double amplitude Shock: Mechanical endurance: 1 000m/Sec² approx. 100G S False action endurance: 300m/Sec² approx. 30G S Ambient Temperature: When in use: -10°C ~ +80°C no icing Humidity:
